ESYLUX EC10430930 Interface Push Button 8xDALITW
EAN:
Part number:
Item no:
Technical specifications
- KNX bus system: no.
- KNX radio bus system: no.
- Bus system Radio bus: no.
- Bus system LON: no.
- Bus system Powernet: no.
- Other bus systems: None
- Bidirectional radio: no.
- Mounting type: Flush-mounted
- With theft/dismantling protection: no.
- With bus connection: Yes
- Number of actuation points: 8
- Number of keys: 8
- With LED display: Yes
- With label field: no.
- With display: no.
- Material: Plastic
- Material quality: Thermoplastic
- Surface: Untreated
- Surface type: Matt
- RAL number (similar): 9003
- Transparent: no.
- With room thermostat: no.
- With infrared sensor: no.
- Min Depth of device socket: 8 mm
- Product type
Interface
IP20
- Data transfer (Smart Home)
Wired
- Channels
2
- Mounting type
Flush mount
- Factory colour
White
- Width
71 mm
- Height
21.5 mm
- Depth
71 mm
- Dim
(W x H x D) 71 x 21.5 x 71 mm
- Hub
Not required, optional for remote access
n.rel.
- Weight
64 g
- Features
Dimmer function
- Similar RAL
9003
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1965746 ESYLUX EC10430930 Interface Push Button 8xDALITW
Description
DALI 8-way button, tunable white. For controlling light scenes and for manually oversteering lights. Standard functions: On, off, dim. Three light scenes can be created and stored individually. Reactivate SymbiLogic after manual override.
