ESYLUX EN10061837 Escape route lighting EEC Special light bulbs Ceiling mount Right
EAN:
Part number:
Item no:
Technical specifications
- Dim
(L x W x H) 306 x 72 x 170 mm
- Product type
Escape route lighting
- Main battery supply
No
- Max. battery life
8 h
- Type
Right
- Operating voltage
230 V AC
- Detection range
30 m
4 W
- Bulb type
LED (monochrome)
- Material
Plastic
- Mounting type
Ceiling mount
- Number of pins
7
- Width
72 mm
- Height
170 mm
- Depth
306 mm
IP54
- Protection class
II
- Length
306 mm
72
2.5 mm²
6
306 m
170 mm
230-230 V
TRUE
5 W
65 lm
FALSE
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1961786 ESYLUX EN10061837 Escape route lighting EEC Special light bulbs Ceiling mount Right
Description
Single battery emergency lamp with 3 h / 8 h emergency lighting duration and 30 m detection distance for ceiling mounting with self-monitoring (SC) and fail-safe contact (opens when the error). 3 h mode uses the pictogram lighting and downlight function/8h mode uses the pictogram lighting in emergency operation. Additional Remote Switch Connection (F +, F) to deactivate the emergency light function when not in use of the building. Function control and self monitoring conventionally with test button or comfortable with remote control mobile-SLi remotely triggered, permanent monitoring the charging process, automatic, weekly function test and annual operating time test, display of the test results through colored LEDs (green/red). Duration and the readiness circuit. Additional bottom light emission. Including Nimh rechargeable battery with reverse polarity protection plug connection. Connection by means of a plug-in terminals. Cable entry either from the rear or top (self-sealing membrane). Housing made of ABS.
This text is machine translated.
This text is machine translated.
Features
- Suitable for type of identification=insert sheet/plate
- Type of identification=one-/two-sided
- With pictogram=yes
- Monitoring device=automatic self-test
- Switching mode=continuous switching/standby switching
- With remote switch connection=yes
- Infeed=decentralized (single battery)
- Battery type=NiMH
- Illuminant=LED not replaceable
- With bulb=yes
- Suitable for number of bulbs=1
- Socket=other
- Number of lamp heads=1
- Material of the housing=plastic
- Housing color=white
- Cover material = transparent plastic
- Light distributor=other
- Lamp with limited surface temperature "D-mark"=no.
- Rated ambient temperature according to IEC62722-2-1=5..35 °C.
- Color temperature=5000..5000 K.
- Type of wiring=suitable for through-wiring
- Conductor cross-section=1.5 mm²
- Connection type=plug connection.
