Eurolite 41602129 THA-100F TRC LED pin spot No. of LEDs (details):1 100 W
EAN:
Part number:
Item no:
Highlights & Details
Eurolite LED THA-100F TRC theater-spot SW
- Fresnel spotlight with 100 W white light LED, color reproduction (CRI) 90
- Sturdy metal housing
- 1 powerful LED 100 W COB (chip-on-board) warm white (WW)
- The device is cooled by a temperature controlled fan
Technical specifications
- Product type
LED pin spot
120 W
- LEDs
1
- Colour
Warm white
- Dim
(L x W x H) 470 x 310 x 390 mm
- Weight
7.15 kg
n.rel.
- Features
Dimmable
- Factory colour
Black
- Bulb type
LED (monochrome)
- Width
310 mm
- Height
390 mm
- Length
470 mm
- Watt per LED
100 W
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3131208 Eurolite 41602129 THA-100F TRC LED pin spot No. of LEDs (details):1 100 W
Description
Can be controlled via speed selection potentiometer for brightness
Stand-alone
Flicker-free
With a beam angle of 9° - 60°
Very high color rendering index (CRI)
With mounting bracket
Ideal for applications such as trade fairs and shops; mobile use; restaurants, bars and hotels; video and photography
Electronic dimmer
Rubber feet
Very quiet operation
Possible application: On-the-fly; on a tripod
This text is machine translated.
Stand-alone
Flicker-free
With a beam angle of 9° - 60°
Very high color rendering index (CRI)
With mounting bracket
Ideal for applications such as trade fairs and shops; mobile use; restaurants, bars and hotels; video and photography
Electronic dimmer
Rubber feet
Very quiet operation
Possible application: On-the-fly; on a tripod
This text is machine translated.
Features
- Power supply 230 V AC 50 Hz
- Total connected wattage 120 W
- Power connection: Fixed power connection cable with protective contact plug
- Protection class SK I
- Cooling: Fan temperature controlled
- Housing colour black.
- Protection class: IP20
- Supporting system: Mounting bracket
- Control: Speed dial potentiometer for brightness
- Transport aid: Rubber feet
- Width 31 cm
- LED:1 x 100 W COB (chip-on-board) warm white (WW)
- Colour temperature: 3200K
- Angle of radiation 9° - 60°
- Max. Beam angle: 1/2 peak, 9 - 40°
- Max. Beam angle: 1/10 peak, 18 - 60°
- Colour rendering index (CRI): 97 Ra
- Noise classification: Class 1 (very light noise, suitable for noise-sensitive environments)
- 5 x 20 mm, T 2 A fuse can be replaced
- Luminous flux: 5833 lm
- ENERGY EFFICIENCY CLASS (A - G): G.
- Illuminance (lx): 1151 lx
- Wide warm white (WW) 1m: 210 lx
- Stand-alone: Stand-alone
Scope of delivery
- Headlamps
- User manual
- Filter frame
- Barn Doors
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
