Eurolite 41700548 AKKU IP UP-4 QCL MK2 DMX LED effect light No. of LEDs (details):4 10 W
EAN:
Part number:
Item no:
Technical specifications
- Product type
DMX LED effect light
40 W
- LEDs
4
- Colour
RGBW
- Dim
(W x H x D) 17.9 x 19.8 x 15.0 cm
- Weight
4.57 kg
n.rel.
- Features
Battery-powered
- Factory colour
Black
- Bulb type
LED (monochrome)
- Width
17.9 cm
- Height
19.8 cm
- Watt per LED
10 W
- Depth
15.0 cm
IP65
- Case colour
Black
- Material
Aluminium
- Radiation angle
8°
- Protection class
I
- Operating voltage
100-240 V/AC, 50/60 Hz
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3642530 Eurolite 41700548 AKKU IP UP-4 QCL MK2 DMX LED effect light No. of LEDs (details):4 10 W
Description
Weather-proof (IP65) battery-LED uplight with 10 W-4in1 LEDs and QuickDMX. Integrated QuickDMX transceiver for wireless DMX control. Wireless, flexible and versatile. Operating time up to 5.5 h, depending on the program used. Integrated automatic charging and status display. 4 powerful LEDs 10 W SMD 5050 4in1 QCL RGBW (homogeneous color mixing). Frost filter Electronic dimmer; adjustable dimmer speed (step response); variable color mixing; variable speed color cross-fading; variable speed color change; colors pre-set, adjustable white balance, manual program selection; pulse width modulation; energy-saving mode; Emergency lighting function in case of power failure. Wash-Effect; Stroboscope-Effect. 36 integrated show programs. Direct color selection for 15 preset colors. The device is cooled by passive convection cooling. Can be controlled via stand-alone; IR remote control; DMX; QuickDMX; RDM; Master/slave function; wireless Master/slave function. Flicker-free. DMX failure mode (blackout; hold; static; full on). With an angle of radiation of 8°. With mounting bracket; with bracket for setting up on the ground, with Omega bracket. OLED Display Battery level indicator Displays the remaining battery life for the current setting. SEETRONIC plug-in connection installed. Suitable for outdoor areas IP65. With pressure equalization membrane. With an Kensington-LOCK anti-theft device. For applications such as: Architecture; Decoration; Wedding/Gala/Events; Mobile DJ's / solo entertainer; Restaurants, Bars and Hotels; Renters; Advertising/Showcase. Noiseless operation Possible application: Standing; flying. 3 buttons of the remote control to store your own settings
This text is machine translated.
This text is machine translated.
Features
- Power supply: 100-240 V AC, 50/60 Hz; protection type: IP65; protection class: SK I; power connection: Power supply via IP T-Con (M) Installation version Power connection cable with safety plug; construction cable: 3 x 1.5 mm² H07RN-F; battery type: 1 x Lithium-Ion 14.8 V, 6600 mAh, 97.68 Wh; battery: Operating time up to 5.5 h depending on the program used; charging time 3h; lamp type: LED lamp; LED type: 4 x 10 W SMD 5050 4in1 QCL RGBW (homogeneous color mixing); features: frost filter; DMX channels: 3, 4, 6; 8; 11; DMX input: 3-pin XLR (M) mounting version IP; DMX output: 3-pin XLR (W) mounting version IP; Cooling: passive convection cooling; control: stand-alone; IR remote control; DMX; QuickDMX; RDM; Master/Slave function; wireless Master/Slave function; Projection: flicker-free; PWM frequency: 3000 Hz; carrier frequency: 2.4 GHz; DMX failure mode: blackout; hold; static; Full on; angle of radiation: 8°; angle of radiation (1/2 peak): 8°; angle of radiation (1/10 peak): 17°; housing color: black; photograph system: mounting bracket; bracket for setting up on the ground; Omega bracket; display type: OLED display; display: charging status display, battery time calculation; Diameter Mounting holes: 1 x Ø10mm; Brand applications: SEETRONIC Plug-in connection installed; Material: Aluminium; Theft protection: Kensington-LOCK; Dimensions: Width: 4.57 cm; Depth: 15.0 cm; Height: 19.8 cm; Weight: 17.9 kg; Noise classification: Class 0 (no noise); Remote control; Battery: 1 x button cell 3.0 V CR2032 Lithium-manganese installed; Legal specifications; Special product: Not intended for room lighting in households; Intended use: lighting for show effects
Scope of delivery
- 1 x spotlights
- 1x user manual
- 1 x Power cable/power cable
- 1 x frost filters
- 1x remote control
- 1 x battery
- 2 x Knurled screw
- 1 x mounting bracket
- - 2 x screws
- 4 x washers
- 1 x Omega clip.
