Eurolite LED pin spot LED PFE-60 RGBW Warm white to cool white, Super warm white 60 W
EAN:
Part number:
Item no:
Highlights & Details
Eurolite LED PFE-60 RGBW Profile Spot 9-25°
- 1 powerful LED 80 W COB (chip-on-board) 4in1 QCL RGBW (homogeneous color mixing)
- Variable color temperature 1800 K - 10000 K
- With a beam angle of 9° - 25°
Technical specifications
- Product type
LED pin spot
- Case colour
Black
60 W
- Dim
(L x W x H) 425 x 255 x 160 mm
- Weight
3.4 kg
n.rel.
- Colour
Warm white to cool white
Super warm white
1080 K
- Width
255 mm
- Height
160 mm
- Length
425 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3131271 Eurolite LED pin spot LED PFE-60 RGBW Warm white to cool white, Super warm white 60 W
Description
Profile headlights, 80 W 4in1 LED (RGBW), manual Zoom, aperture slider
For application areas like: Theatre; stage; installation; distributors
This text is machine translated.
For application areas like: Theatre; stage; installation; distributors
This text is machine translated.
Features
- Zoom manual; focus manual
- Colour mixing infinitely variable, color change adjustable, color cross-fading adjustable, dimmer electronic, pulse width modulation variable
- Stroboscope-effect
- Flicker-free
- The device is cooled by a temperature controlled fan
- Can be controlled via stand-alone; DMX; RDM; Master/Slave function
- Multi-colored OLED display
- With mounting bracket
- Pre-programmed by Light Captain
- Very quiet operation
- Possible application: On-the-fly; on a tripod
- Power supply: 100 - -240 V AC 50/ 60 Hz
- Total connected wattage 60 W
- Power connection: Fixed power connection cable with protective contact plug
- Display type: Multicolor OLED display
- Protection class SK I
- Cooling: Fan temperature controlled
- Housing colour black.
- Protection class: IP20
- Supporting system: Mounting bracket
- Control: Stand-alone
- Width: 16.0 cm
- LED lamp type
- 1 x 80 W COB (chip-on-board) 4in1 QCL RGBW (homogeneous color mixing)
- Adjustable color temperature 1800K - 1000K
- Equipment: Manual Zoom
- Manual focus: Manual focus
- DMX input 1 x 3-pin XLR (M) installation version
- Master/slave function
- Pre-programmed with: Light Captain
- Angle of radiation 9° - 25°
- Max. Beam angle: 1/2 peak, 9 - 25°
- Max. Beam angle: 1/10 peak, 9 - 25°
- Noise classification: Class 1 (very light noise, suitable for noise-sensitive environments)
- Gobos: Outer diameter 37mm
- DMX output 1 x 3-pin XLR (W) built-in version
- Life: 50,000 h
- Luminous flux: 5000 lm
- Image diameter 25mm
Scope of delivery
- Headlamps
- Gobo holder
- User manual
