EVN P20402 P20402 LED recessed wall light LED (monochrome) Built-in LED 2 W White
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Power-LED WALL BUILD-IN LAMP, IP54
- Power= 2 W Colour temperature= 3000 K Warm white
Technical specifications
- Product type
LED recessed wall light
Built-in LED
- Bulb type
LED (monochrome)
- Rating per bulb
2 W
2 W
3000 K
- Colour
Warm white
- Protection screen
Clear
- Radiation angle
80°
- Light features
Recess mount option
- Recess diameter
60 mm
- Recess depth
30 mm
IP54
- Protection class
III
- Factory colour
White
- Material
Aluminium
n.rel.
- Dim
(L x W x H) 80 x 80 x 30 mm
- Light bulb included
Yes
- Colour temperature (max.)
3000 K
- Colour temperature (min.)
3000 K
- Colour temperature range
3000 - 3000 K
- Width
80 mm
- Height
30 mm
- Length
80 mm
- Rated luminous flux
112 lm
- Number of pins
2
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2483982 EVN P20402 P20402 LED recessed wall light LED (monochrome) Built-in LED 2 W White
User & Safety Instructions
User & Safety Instructions 2483982 EVN P20402 P20402 LED recessed wall light LED (monochrome) Built-in LED 2 W White
Description
The recessed LED light is designed in such a way that it can be mounted either in the wall or alternatively in switch boxes. The color of the lamp is RAL9003. Due to its design and power, the lamp is perfectly suitable as an orientation lamp. Since the lamp is operated via 700mA, the lights must be switched in series. The lamp has a 0.5m long connection cable.
