Fibox NEO PC 322215 G 4810000 Wall-mount enclosure 220 x 320 x 150 Polycarbonate (PC) anti-corrosive Grey-white (RAL 703
EAN:
Part number:
Item no:
Product type
Wall-mount enclosure
Material
Polycarbonate (PC)
IP rating
IP66/IP67
Width
220 mm
Height
320 mm
Datasheet (PDF)
Highlights & Details
Housing, Fibox, NEO PC 322215 G, 320x220x150 mm, polycarbonate, IP 66/67, RAL 7035 - light gray
- High degree of protectionCorrosion-resistantCover screws made of stainless steelIntegrated rain roofMaximum installation spaceQuick installationDoor with a wide opening angle of 180°
Technical specifications
- Product type
Wall-mount enclosure
- Features
Cover (gray)
- Material
Polycarbonate (PC)
IP66/IP67
- Factory colour
Grey-white (RAL 7035)
- Width
220 mm
- Height
320 mm
- Content
1 pc(s)
- Dim
(W x H x D) 220 x 320 x 150 mm
- Weight
1.8520 kg
- Material properties
anti-corrosive
- Depth
150 mm
- Type
NEO PC 322215 G
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2523827 Fibox NEO PC 322215 G 4810000 Wall-mount enclosure 220 x 320 x 150 Polycarbonate (PC) anti-corrosive Grey-white (RAL 703
User & Safety Instructions
User & Safety Instructions 2523827 Fibox NEO PC 322215 G 4810000 Wall-mount enclosure 220 x 320 x 150 Polycarbonate (PC) anti-corrosive Grey-white (RAL 703
Description
The new housing option - NEO - is the clear choice if you need a very protective and robust solution. NEO is double insulated and has double-walled floor corners as well as an integrated rain protection roof. It is very easy and quick to install, as it has an additional installation room and large areas for individual design and easy maintenance. Thanks to its reinforced construction, NEO offers permanent, optimized safety and additional protection against mechanical stress and corrosive substances in modern clothing. NEO is specially designed for all applications in the areas of industrial control, IoT and building automation, and NEO combines the best housing features of screw cap and switch cabinet solution.
