Finder 38.81.7.024.9024 - 2A Relay Interface Module, SSR, N/A 24V DC
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 27.72
3
4% = € 1.21
€ 26.51
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 27.72 / piece)
€
Highlights & Details
Coupling component
- N/A solid state relay
- contacts
- Screw terminal
- Instant ejection of relay by plastic retaining clip
- Integral coil indication and protection circuit
- 35mm rail (EN 60715) mounting
Technical specifications
- Relay protection RT III
- Type
38.81.7.024.9024
- Connection
Screw terminal
- Control voltage (min.)
24 V DC
- Control voltage (max.)
24 V DC
- Control voltage range
24 - 24 V DC
- Switching voltage (max.)
24 V DC
- Current load (max.)
6 A
- Contact type
1 maker
- Min. temperature
-20 °C
- Max. temperature
+55 °C
- Width
6.2 mm
- Height
75.6 mm
- Length
87.9 mm
- Electrical lifespan
Optocoupler
- RoHS-compliant
- Content
1 pc(s)
- Type
SSR-coupler component 38.81 screw socket
- Nominal voltage (details)
24 V DC
- Switching voltage
24 V DC
- Switching current
2 A
- Ambient temperature
-20 - +55 °C
- Durability
Optocoupler
- Connection
Screw terminal
- Product type
SSR
Documents & Downloads
Datasheet
Datasheet 503512 Finder 38.81.7.024.9024 - 2A Relay Interface Module, SSR, N/A 24V DC
Datasheet 503512 Finder 38.81.7.024.9024 - 2A Relay Interface Module, SSR, N/A 24V DC
User & Safety Instructions
User & Safety Instructions 503512 Finder 38.81.7.024.9024 - 2A Relay Interface Module, SSR, N/A 24V DC
Description
Mounted coupler relay. Positive isolation to VDE 0160/EN 50178.
Scope of delivery
- SSR-Relay 34.81
- Screw socket 93.01
- LED
- Free wheel and polarity-reversal protection diode
- Holding / dismantling clip.
Hints
Approvals: UL / CSA.
