Fischer 522115 Cavity fixing 75 mm 10 mm 50 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Thread: M 10 x 33 mm
- U-DISC outside diameter x thickness: 25 x 3 mm
- Min. Drill hole depth for through-hole mounting: 65 mm
- Width 17 mm
- (Ø)
10 mm
- Product type
Cavity fixing
- Material
Steel
- Length
75 mm
- Screw diameter
10 mm
- Dim
(Ø x H) 10 mm x 75 mm
- Suitable for
Concrete
- Content
50 pc(s)
- Outside Ø
10 mm
- Features
incl. washer
- Material properties
zinc galvanized
- Height
75 mm
17 mm
75 m
Metric
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1878070 Fischer 522115 Cavity fixing 75 mm 10 mm 50 pc(s)
Description
The fischer FAZ II anchor bolt K GS with large disc is the steel anchors for highest demands. With the steel armature is made from electro-galvanised, heavy loads in gerissenem concrete attached. The FAZ II K GS. thanks to the easy installation and the low anchoring depth especially can be used flexibly. The proven spread clip conducts the loads particularly securely in the concrete and enables the highest load capacity.
