Name: FRITZ! FRITZ!Box 5530 Fiber Wi-Fi FO router 2.4 GHz, 5 GHz
Brand: FRITZ!
SKU: 2349755

A white and red router with the label 'FRITZ!Box'. Four green LED lights indicate operational states, including internet connection.

'FRITZ!Box 5530 Fibre', fibre optic router for home networks, supports Wi-Fi 6, WLAN Mesh, telephone/DECT. Ideal for speeds up to 6 Gbps.

Wi-Fi 6 router connected to a fibre-optic connection. Front view displaying indicator lights and an Ethernet cable.

'Installing the FRITZ!Box 5530 Fiber in 4 Steps': Images show exemplary fibre optic socket, router connection, user interface, router benefits.

Router rear panel with ports: Fibre optic, one analogue port, a 2.5 Gigabit LAN, two 1 Gigabit LAN and 2x2 Wi-Fi 6.

The FRITZ!Box 5530 Fiber with Wi-Fi 6 and fibre optic connection offers 2400 Mbps wireless connectivity, a 2.5-Gigabit LAN connection, and telephony functionality.

1/6

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

AVM FRITZ!Box 5530 Fiber

Router with integrated glass fiber modem for direct connection to all common glass fiber connections in GermanySupplied fully equipped for the connections of national, regional and local network operators (fiber optic standards AON and GPON)Wi-Fi 6 with 2,400 MBit/s (5 GHz) and 600 MBit/s (2.4 GHz) for stable Gigabit speeds in a variety of terminalsMesh Master function: FRITZ!Box supports distributed WLAN access points (e.g. FRITZ!Repeater) to create a dynamic intelligent WLAN networkVoIP telephone system with versatile comfort functions for all telephones (analogue, DECT and IP telephones), DECT base station for up to six cordless telephones, e. B. All FRITZ!Fon models2 x Gigabit LAN connections, 1 x 2.5 Gigabit LAN connection, SFP cable for a FRITZ!SFP module

Pre-contractual information under the EU Data Act

Technical specifications

Product type: Wi-Fi FO router

Type: FRITZ!Box 5530 Fiber

Function: DECT hub
Router

Wi-Fi standard: IEEE802.11ac
IEEE802.11n
IEEE802.11g
IEEE802.11b
IEEE802.11a
IEEE802.11ax

Dual Band compatibility: 2.4 GHz and 5 GHz

Wi-Fi frequency band: 2.4 GHz
5 GHz

Wi-Fi speed 2.4 GHz: 600 MBit/s

Wi-Fi speed 5 GHz: 2.4 GBit/s

LAN data transfer rate: 2.5 GBit/s

Interfaces: SFP
Gigabit LAN (1/2.5 Gbps)
Wi-Fi 6 (IEEE 802.11ax)
Phone (analog)

Features: Mesh support

WPS compatible: Yes

a/b ports: 1 x

Answerphone: Yes

Width: 150 mm

Height: 208 mm

Depth: 37 mm

Weight: 730 g

Factory colour: Red/white

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 2349755 FRITZ! FRITZ!Box 5530 Fiber Wi-Fi FO router 2.4 GHz, 5 GHz

Information

Information 2349755 FRITZ! FRITZ!Box 5530 Fiber Wi-Fi FO router 2.4 GHz, 5 GHz

Description

Fibre-optic power with fast Wi-Fi 6The FRITZ!Box 5530 Fiber brings the full FRITZ!Box functionality to the fiber connection while offering maximum flexibility. The latest WLAN generation Wi-Fi 6 is also present on board as are the interfaces of telephone.With the FRITZ!Box 5530 Fiber you can use a variety of fiber modules. The matching SFP modules of the FRITZ!Box are included for both the most common types of connections, AON and GPON.Optimum data throughput with Wi-Fi 6The new Wi-Fi 6 standard supports the constantly growing number of WLAN devices. Through reduction of latency Wi-Fi 6 provides for a fast, stable data flow. A total bandwidth of 2,400 Mbit/s (5 GHz) and 600 MBit/s (2.4 GHz) is available for many parallel applications.Strong as the central unit in the WLAN meshAs a WLAN Mesh center the FRITZ!Box 5530 Fiber is ready for the highest demands of the home network. In WLAN mesh, distributed WLAN nodes (e.g. FRITZ!Box and multiple FRITZ!Mesh Repeaters) form a single intelligent WLAN network.The FRITZ! Box 5530 Fiber forms the headquarters of the FRITZ! Mesh and actively controls all other access points so that WLAN terminals used in the home network are always logged in at the access point with the best connection (WLAN mesh steering).Connectivity
· 2.5 Gigabit LAN port (standard IEEE 802.3bz, NBase-T)· 2 ultra-fast Gigabit LAN ports for computers, TVs, and other network devices· 1 analogue telephone connection· SFP cage for a FRITZ!SFP module (AON and GPON included)

This text is machine translated.
