Name: FRITZFURT Drill stand Operating height (max.): 230 mm (L x W x H) 260 x 180 x 360 mm
Brand: FRITZFURT
SKU: 3208310
Availability: BackOrder

Drill stand on a workbench in a workshop. 'Fritzfurt' printed on it. Background with blurred tool shelves.

Vice and accessories on a workbench, with blurred workshop shelves in the background.

A person is drilling a hole in a wooden board using a blue drill stand. The drill stand is marked with the inscription 'FRITZFURT'.

A hand operates a blue pillar drill, boring a hole into a wooden block. The background is out of focus.

A blue rotary knob in the centre controls the angles of a mechanical joint that can pivot into various positions.

1/5

Application

Dispatches on Tue 20 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 77.99 / piece)

€ 77.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

FRITZURT adjustable drill stand 0-60°

Delivers exceptional precision and versatility for professional commercial drilling tasks
Optimized dimensions maximize workspace efficiency to accommodate diverse project requirements
Solid aluminum construction with precision ball bearings ensures consistently smooth operation

Technical specifications

Material: Aluminum 6061 base, guide block, and handle; alloy steel fixing rod
Drill chuck: 1 - 10 mm
Chuck capacity: 1 mm to 10 mm
Chuck shank: 6.35 mm (1/4"") quick-change hex
Drilling angles: +/- 60°
Chuck travel: 215 mm
Distance between bars: 90 mm
Chuck tip to base underside: 240 mm
Base aperture: 105 mm x 75 mm

Product type: Drill stand

Operating height (max.): 230 mm

Length: 260 mm

Width: 180 mm

Height: 360 mm

Weight: 2.8 kg

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3208310 FRITZFURT Drill stand Operating height (max.): 230 mm (L x W x H) 260 x 180 x 360 mm

Description

The FRITZURT drill stand is versatile, perfect for straight or angled drilling, professional for working on the edge of a board or round material.
Precise drilling and adjustable angle, each angle from 0° to 60° with the help of the easy to read angle gauge scale.
Sturdy aluminum base to prevent tilting.

This text is machine translated.

Features

Versatile 10 mm chuck accommodates a wide variety of commercial drill bits.
Provides 210 mm maximum travel distance and 230 mm of chuck-to-base clearance.
Broad drilling angle range is easily adjustable from 0° to ±60°.
Integral V-guides securely stabilize round stock and pipes during drilling operations.

Scope of delivery

Fritzfurt drill stand

Description

Features

Versatile 10 mm chuck accommodates a wide variety of commercial drill bits.
Provides 210 mm maximum travel distance and 230 mm of chuck-to-base clearance.
Broad drilling angle range is easily adjustable from 0° to ±60°.
Integral V-guides securely stabilize round stock and pipes during drilling operations.
