Gaptec 5AC1D_05S3.6 AC/DC converter 5 V DC 1200 mA 5 W
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
AC/DC converter output: 5V 85-265VAC, 120-380VDC
- Output 5 V DC / 1200 mA
- Power 5 W
Technical specifications
- Product type
AC/DC converter
- Input voltage (max.)
265 V AC
380 V DC
- Max. output current
1200 mA
- Output current (max.) - rounded
1.2 A
- Min. input voltage
85 V AC
120 V DC
- Dim
(L x W x H) 39.0 x 25.0 x 22.0 mm
- Output voltage (max.)
5 V DC
5 W
- Operating temperature (max.)
75 °C
- Operating temperature (min.)
-40 °C
- Weight
24 g
- Width
25.0 mm
- Height
22.0 mm
- Length
39.0 mm
- Type
5AC1D_3.6
- Enclosure
DIP 7 (6-pin)
- Efficiency
75 %
Documents & Downloads
Datasheet
Datasheet 3355895 Gaptec 5AC1D_05S3.6 AC/DC converter 5 V DC 1200 mA 5 W
User & Safety Instructions
User & Safety Instructions 3355895 Gaptec 5AC1D_05S3.6 AC/DC converter 5 V DC 1200 mA 5 W
Description
AC/DC converter output: 5V 85-265VAC, 120-380VDC
