Gossen Metrawatt METRAVOLT VT 1500 Two-pole voltage tester CAT IV 1000 V LCD, LED
EAN:
Part number:
Item no:
Number
Total (€ 536.97 / piece)
€
Only 2 Piece(s) available
Highlights & Details
Voltage and continuity tester according to DIN EN 61243-3 to 1,000 V AC / 1,500 V DC
- Fully automatic measurement sequence
- Measurement storage
- Self-test and battery check
- Battery level indicator
- Robust housing
- High safety (series resistors in the two test probes)
Technical specifications
- Load switching
40 mA
IP65
- Dim
(L x W x H) 275 x 89 x 35 mm
- Weight
270 g
- Height
35 mm
- Length
275 mm
- Width
89 mm
- Max. frequency
10 kHz
- Frequency range
16.7 Hz - 10 kHz
- V AC reading range
100 up to 1200 V
- V DC reading range
100 up to 1500 V
Manufacturer's standards (no certificate)
- Display
LCD
LED
- Reading category
CAT IV 1000 V
- Reading type
Rotating magnetic field
Continuity
Resistance
Phase
FI
- Type
METRAVOLT VT 1500
- Min. frequency
16.7 Hz
- V AC reading range (max.)
1200 V
- V AC reading range (min.)
100 mV
- Voltage DC reading range (max.)
1500 V
- Voltage reading range DC (min.)
100 mV
- Product type
Two-pole voltage tester
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2362170 Gossen Metrawatt METRAVOLT VT 1500 Two-pole voltage tester CAT IV 1000 V LCD, LED
Description
Two-pole, digitally indicating voltage tester, combined with a continuity, phase and rotary field tester. With this you can safely determine the presence and height of alternating or direct voltage from 0 V to 1000 V AC / 1500 V DC at frequencies up to 2 kHz. With the integrated continuity tester, you can also measure resistances in the range from 0 to 999 k. Voltage and resistance values are displayed digitally on an LC display. In addition, LEDs and display color indicate red contact-dangerous voltage and direction of rotating field.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Voltage tester with batteries
