Buy Gossen Metrawatt PROFiTEST MF XTRA VDE tester, Electrical tester Calibrated to (DAkkS standards) VDE standard 0100, 0100

A multifunction test meter for checking electrical installations, displaying resistance, voltage and other measurement values on a display.

Datasheet (PDF)

4 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 3,268.07 / piece)

€

Only 4 Piece(s) available

Report legal concerns

Highlights & Details

Measuring and testing device for testing the effectiveness of protective measures in stationary electrical installations.

Context-sensitive color graphic displayMeasurement and test procedure - simple creation of the plant structure / measuring & saving / generating logs Pre-configured and self-programmable test sequences for quick testing of electrical systems Memory concept for up to 50,000 recordsTesting all current all-current sensitive RCDs, RDC-DD, RCMBProtection of the operator by PE detection when used by finger contactTest of differential current monitoring devicesTesting of insulation monitoring devicesFuture-oriented connectivityFour-wire measuring technology - no compensation of the measurement leads required

Technical specifications

Product type: VDE tester

: DAkkS standards

Reading category: CAT III 600 V
CAT IV 300 V

Interfaces: USB

Dim: (L x W x H) 330 x 260 x 90 mm

Weight: 2.7 kg

: IP40

Reading range (VDE): Loop impedance
Earth fault loop impedance
RCD testing (AC, A, F, B, B+, EV)
PRCD testing (2-pin, 3-pin, PRCDS, PRCDS+, PRCDK)
Insulation resistance
Earth resistance
Earth leakage resistance
Earth leakage current
Voltage
Current
Frequency
Resistance
Touch voltage
Show more

DIN standard: DIN VDE 0100
DIN VDE 0105
DIN VDE 0413
DIN EN 61557
DIN EN 61010-1

Display type: Digital

Reading range

Width: 260 mm

Height: 90 mm

Length: 330 mm

Test procedure: automated
manual

Voltage supply: Rechargeable
Battery

Memory (space): 50000

Memory: Yes

Type: PROFiTEST MF XTRA

VDE standard: 0100
0100-600
0105
0113
0411
0413

Features: incl. software

Factory colour: Multicolour

Documents & Downloads

Datasheet

Datasheet 2730557 Gossen Metrawatt PROFiTEST MF XTRA VDE tester, Electrical tester Calibrated to (DAkkS standards) VDE standard 0100, 0100

User & Safety Instructions

User & Safety Instructions 2730557 Gossen Metrawatt PROFiTEST MF XTRA VDE tester, Electrical tester Calibrated to (DAkkS standards) VDE standard 0100, 0100

Description

The PROFITEST MF XTRA makes the investment decision easy for you. With the test range that is perfectly tailored to your requirements, the professional electrician is the ideal test device for your daily routine – day after day. With its optimal operation and the memory concept, creating a test log is easy and quick. This saves you time during each test and allows you to perform more tests daily. Once a plant structure has been created, you can also use it across all PROFITEST devices. Each employee therefore always checks exactly the same.

This text is machine translated.

Features

DisplayContext-sensitive color graphic display Soft key buttons Allows you to conveniently select sub-functions And parameters. Unavailable subfunctions and Parameters are automatically hidden.Special measurementsSelective earth resistance RE (mains operation)With 2-pin adapter, probe, earthing and clip-on current sensor(3-pole measurement method)Measurement potential equalizationCurrent measurement with pliers Field directionEarth leakage resistance RE(ISO)Voltage dropLocation isolation ZSTCounter start (kWh test)Testing of E-loading columns andElectric vehicles on E-loading pillars (IEC 61851-1)Earthing resistance RE (battery-operated)3- or 4-pole measurement method via adapter PRO-RESpecific earth resistance (battery-operated)(4-pole measurement method via adapter PRO-RE)Testing of insulation monitoring devices (IMDS)Checking differential current monitoring devices (RCMS)Leakage current with Adapter PRO-ABCheck residual voltage (Ures) Intelligent ramp for RCD testing(Testing tripping time and tripping current with only one measurement)Logging of error simulations on PRCDs with thePROFITEST PRCD adapterInclusive IZYTRONIQ database software for managing equipment, machinery, equipment and medical devices in combination with locations across a double tree structure and for managing auditors, test equipment, catalogs and sequences.

Scope of delivery

1X PROFESSIONAL TESTING MF XTRA1x protective contact plug insert (country-specific)1x 2-pin measuring adapter and1x cable for extension to 3-pin adapter (PRO-A3-II)2x alligator clips1x shoulder strap1x set of batteries (Z502H)1x charger (Z502R)1x quick user manual1x Safety information leaflet1x DAkkS calibration certificate1x/USB-interface cable1x IZYTRONIQ BUSINESS Starter Software License 1x Cloud voucher 12 months
