Greisinger GMH3651 Multi tester O2 concentration, O2 saturation, Pressure, Temperature
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Greisinger handheld dissolved oxygen meter with GMH 3651 data logger
- Measuring ranges: O2 concentration 0.00 to 70.00 mg/l; O2 saturation 0.0 to 600.0 % O2 (resolution selectable); O2 partial pressure: 0 to 1200 hPa O2.
- Temperature measurement range: 0.0 to 50.0 °C.
- Accuracy: Oxygen: ±1.5 % of MW ±0.2 mg/l (0…25 mg/l) or ±2.5 % of MW ±0.3 mg/l (25…75 mg/l)
Technical specifications
- Measuring ranges: O2 concentration 0.00 to 70.00 mg/l; O2 saturation 0.0 to 600.0 % O2 (resolution selectable); O2 partial pressure: 0 to 1200 hPa O2.
- Product type
Multi tester
- Reading type
O2 concentration
O2 saturation
Pressure
Temperature
- Accuracy
Oxygen: ±1.5 % of MW ±0.2 mg/l (0…25 mg/l) or ±2.5 % of MW ±0.3 mg/l (25…75 mg/l)
- Display
LCD
Manufacturer's standards (no certificate)
- Automatic temperature compensation
Yes
- Power supply (details)
9 V batteries
- Dim
(L x W x H) 26 x 71 x 142 mm
- Weight
300 g
- Temperature reading range
0.0 up to 50.0 °C
- Temperature reading range (max.)
50.0 °C
- Temperature reading range (min.)
0.0 °C
- Width
71 mm
- Height
142 mm
- Length
26 mm
Documents & Downloads
Datasheet
Datasheet 1766320 Greisinger GMH3651 Multi tester O2 concentration, O2 saturation, Pressure, Temperature
User & Safety Instructions
User & Safety Instructions 1766320 Greisinger GMH3651 Multi tester O2 concentration, O2 saturation, Pressure, Temperature
Security datasheet
Security datasheet 1766320 Greisinger GMH3651 Multi tester O2 concentration, O2 saturation, Pressure, Temperature
Signal word
Danger
GHS / H Statements
- H 290: May be corrosive to metals
- H 314: Causes severe skin burns and eye damage
GHS / P Statements
- P 101: If medical advice is needed, have product container or label at hand
- P 102: Keep away from children
- P 103: Read the label before using the product
- P 280: Wear protective gloves/protective clothing/eye protection/face protection
- P 303+361+353: SKIN/HAIR CONTACT: Remove contaminated clothing immediately. Rinse skin with water/shower
- P 305+351+338: CONTACT WITH EYES: Rinse cautiously with water for several minutes. Remove contact lenses if applicable/possible. Continue rinsing
- P 310: Contact Poison Control Center or seek medical advice immediately
- P 390: Collect spillage to prevent material damage
- P 405: Keep locked up
- P 501: Dispose of contents/container at …
Description
Handheld dissolved oxygen meter with GMH3651 data logger.
This text is machine translated.
This text is machine translated.
Features
- Automatic air pressure compensation
- Salinity correction
- Easiest calibration
Scope of delivery
- GMH3651
- Electrode
- GWOK01
- Koh replacement electrolyte
- 9 V batteries
- Test protocol
- Operating instructions
