Name: GSR B00306230 CNC tap metric M10 DIN 371 HSS-G 1 pc(s)
Brand: GSR
SKU: 3730557

A metal spiral drill bit with sharp cutting edges designed for drilling holes in hard materials.

Product type

CNC tap

Thread spec

metric

DIN standard

DIN 371

Thread size

M10

Material

HSS-G

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

HSSG machine tap M10 DIN 371 shape C/RSP 35°

Nominal dimension M 10
DIN standard DIN 371
Tolerance class: 6H
Made from HSS
Groove shape RSP 35°
Hole type: Blind hole
Thread depth:3xD
Square nominal dimensions according to DIN 10: 8.0 mm

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3730557 GSR B00306230 CNC tap metric M10 DIN 371 HSS-G 1 pc(s)

Description

Machine tap drill for blind holes according to DIN 371 with reinforced shaft. 35° right-spiral groove (RSP) provides for reliable chip removal upwards and prevents chip congestion. Annotate form C allows threads close to the base. Precision-ground HSSG ensures dimensional stability, quiet running and a good service life. Suitable for machine and CNC use with emulsion or cutting oil in low and low alloy steels and non-ferrous metals. DIN-371 shank with square for safe power transmission.

This text is machine translated.
