GUDE 7214-11 19 inch Black
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Grade 7214-11 Temperature & Moisture Sensor Internal Temperature sensor Free standing Cable connected
- Free-standing temperature sensor
- Cable connected
- Inside
- Temperature range -20 – 80 oC
- Standard interfaces RJ-45
Technical specifications
- Suitable for server rack cabinet (inch)
19 inch
- Dim
(W x H x D) 90 x 100 x 34 mm
- Cable length
0 m
- Content
1 pc(s)
- Factory colour
Black
- Width
90 mm
- Height
100 mm
- Depth
34 mm
- Keyboard layout
German, QWERTZ
- Type
Free standing
- Sensor type
Temperature sensor
- Transfer type
Corded
- Weight
300 g
- UKCA
yes
- Operating temperature (T-T)
0 - 50 °C
- Temperature measuring range
-20 - 80 °C
- Accuracy
0.6 °C
- Operating relative humidity (H-H)
0 - 95 %
- Storage temperature (T-T)
-20 - 70 °C
Documents & Downloads
Datasheet
Datasheet 3797257 GUDE 7214-11 19 inch Black
User & Safety Instructions
User & Safety Instructions 3797257 GUDE 7214-11 19 inch Black
Description
Standalone LAN sensor for environment and I/O monitoring
The Expert Sensor Box 7214-series enables the environment monitoring of IT installations via TCP/IP networks. Three versions are available with fixed integrated sensors and two sensor connections for extended monitoring. Depending on the model, temperature, humidity and air pressure can be measured with the integrated sensors. The three sensor variants are also available as models with power supply via Power-over-Ethernet (PoE). The devices also have a switchable relay output and a passive signal input, allowing remote control of connected NO/NC devices. The Expert Sensor Box 7214-series is equipped with SNMPv3, SSL and IPv6-capability and supports Telnet, Radius and Modbus TCP.
This text is machine translated.
Features
- Gude Expert Sensor Box 7214-11 - device for keeping an eye on the environment
- Device Type : Device for environmental monitoring
- Form factor : DIN rail mounting possible
- Data Link Protocol : Ethernet, Fast Ethernet
- Power over Ethernet (PoE) support : PoE
- Dimensions (width x depth x height): 10 cm x 3.4 cm x 9 cm
- Weight: 300 g
Scope of delivery
- GUDE 721411 Expert LAN-Sensor for Temperature and I/O-Monitoring, PoE
