Hager HTN380E HTN380E Main RCCB 80 A 400 V
Product type
Main RCCB
Number of pins
3
Release characteristics
E
Nominal current - rounded value
80 A
Nominal current
80 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Main RCCB
- Number of pins
3
- Release characteristics
E
- Nominal current - rounded value
80 A
- Nominal current
80 A
- Dim
(W x H x D) 150 x 100 x 150 mm
- Content
1 pc(s)
- Nominal voltage
400 V
- Width
150 mm
- Height
100 mm
- Depth
150 mm
- Weight
770 g
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3199135 Hager HTN380E HTN380E Main RCCB 80 A 400 V
User & Safety Instructions
User & Safety Instructions 3199135 Hager HTN380E HTN380E Main RCCB 80 A 400 V
Description
SLS switch 3-pin E-characteristic 80A for DIN rail installation. SH-Switch according to DIN VDE 0641-21 and norm size DIN 43880, size 2. SLS in 1-pin or 3-pin design, single-pin switching, with separate contact status indicator. For direct mounting on a DIN rail. The standard (no suggestions) allows for the following locks: For the customer against unintentional or intentional switching, for the installer with a padlock while working in the system, for the VNB with sealing wire, padlock or special key.
