Hager KNX TRB302B Input module 2-channel
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Input module
- Series
KNX
- Transfer Standard (Smart Home)
Manufacturer-specific
- Used at
Indoors
IP20
- Operating voltage
230 V AC
- Data transfer (Smart Home)
Wireless
- Channels
2
- Mounting type
Flush mount
- Factory colour
Grey
- Hub
Not required, optional for remote access
- Data exchange
Unidirectional (uni)
n.rel.
- Weight
0
Flush mounted (plaster)
TRUE
TRUE
FALSE
FALSE
0
None
FALSE
IP20
TRUE
TRUE
FALSE
40
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3198114 Hager KNX TRB302B Input module 2-channel
User & Safety Instructions
User & Safety Instructions 3198114 Hager KNX TRB302B Input module 2-channel
Description
Wireless input flush-mounted, 2 x 230V, Quick link. UP-input device for switching consumers in connection with Quicklink radio products as tool-free Quicklink configuration via buttons with LED display or integration via KNX-radio media coupler into the KNX-TP system. The device converts the switching information of conventional switches/buttons into unidirectional commands. Functions: Switching, dimming, blinds, scenes, timing, Pushbutton NO, forced-control, up/down pushbutton. Mounted in UP socket 60mm.
