HARTING 09 45 551 1123 HARTING 09 45 551 1123 N/A 09455511123 right angle No. of pins (RJ) 8 1 pc(s) 09455511123 right a
EAN:
Part number:
Item no:
Product type
RJ45 connector
Connector type
right angle
No. of pins
8
Specification
CAT 5
Connector standard
RJ45
Datasheet (PDF)
Technical specifications
- Series: Harting RJ INDUSTRIAL®
- Component: Jack
- Connection type: Shaft soldering connection
- Number of contacts: 8
- Rated current 1.5 A
- Temperature limit: -40 ... +85 °C
- Mating cycles ≥ 750
- Net weight: 16 g
- Rated voltage: 125 V
- Data rate: 10 Mbit/s; 100 Mbit/s; 1 Gbit/s; 2.5 Gbit/s.
- Description: RJ45;angled;3 ports
- Shielding: Fully shielded, 360° shield contact
- Transmission features: Cat. 5 class D to 100 MHz
- Protection class according to IEC 60529:IP20
- Approvals DNV GL
- Type
09 45 551 1123
- Product type
RJ45 connector
- Connector type
right angle
- No. of pins
8
CAT 5
- Connector standard
RJ45
- Connection
Soldering
- Type A
Soldering
- Type B
RJ45
- No. of ports
3 x
- Weight
16 g
- Content
1 pc(s)
- Features
shielded housing
- Max. temperature
85 °C
- Min. temperature
-40 °C
Other
125 V
8
Other
-40-85 °C
Other
Soldering connection
Other
Other
Other
Other
1.5 A
Documents & Downloads
Datasheet
Datasheet 3009493 HARTING 09 45 551 1123 HARTING 09 45 551 1123 N/A 09455511123 right angle No. of pins (RJ) 8 1 pc(s) 09455511123 right a
Datasheet 3009493 HARTING 09 45 551 1123 HARTING 09 45 551 1123 N/A 09455511123 right angle No. of pins (RJ) 8 1 pc(s) 09455511123 right a
User & Safety Instructions
User & Safety Instructions 3009493 HARTING 09 45 551 1123 HARTING 09 45 551 1123 N/A 09455511123 right angle No. of pins (RJ) 8 1 pc(s) 09455511123 right a
Description
Jack, RJ45, angled, 3 ports, shaft soldering connection, Rated current 1.5 A, contacts 8
This text is machine translated.
This text is machine translated.
