HARTING 09 66 221 7702 09662217702 Connector Number of pins: 15 Soldering 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Connector
Connector type
Plug, straight
Number of pins
15
Connection
Soldering
Datasheet (PDF)
Highlights & Details
Connectors
- Connector
- No. of rows: 2
- Number of pins: 15
Technical specifications
- Series D-Sub
- Component: Connector
- Contact description: Rotated;straight
- Connection type: Shaft soldering connection
- Type of connection: Motherboard to Daughtercard;mezzanine
- Number of contacts: 15
- Length of the Pins 3.7 mm
- Locking type: Flange with thread 4-40 UNC
- Pitch, connection side 2.74 mm
- Rated current 7.5 A
- Insulation resistance >1010 Ω
- Continuous resistance ≤ 10 mΩ
- Temperature limit: -55 ... +125 °C
- Mating cycles ≥ 50
- Test voltage Ueff 1 kV
- Insulation material group IIIa (175 ≤ CTI < 400)
- Material Application: Thermoplastic molding material, glass fiber reinforced (PBTP);Shell: Steel, with surface finish
- Colour insert: Black
- Material contacts: Copper alloy
- Contact surface: Precious metal over Ni
- Material flammability class acc. To UL 94: V-0
- DIN 41652 standard
- Net weight: 9.8 g
- Designation: Default
- Airway: ≥ 1 mm
- Creepage distance ≥ 1 mm
- Hot plugging: No.
- Circuit board thickness ≥1.6 mm
- Plug-in force ≤ 50 N
- Pull force: ≥ 4.5 N;≤ 33 N
- Gender: Pen
- Tightening torque: ≤0.6 Nm screw bolts
- Size D-Sub 2
- Series distance 2.84 mm
- Installation height: 6.2 mm
- Packaging type
Piece
- Type
D-Sub
- Product type
Connector
- Connector type
Plug, straight
- Number of pins
15
- Connection
Soldering
- No. of rows
2
- Content
1 pc(s)
- Mating cycles
≥ 50
- Manufacturer part #
09662217702
- Factory colour
Black
- Contact type
Machined contacts
- Contact material
Copper alloy
- Contact surface
Precious metal
- CS
2.74 mm
- Features
for wave soldering
- Type
09 66 221 7702
Plug/bus
15
Documents & Downloads
Datasheet
Datasheet 3005272 HARTING 09 66 221 7702 09662217702 Connector Number of pins: 15 Soldering 1 pc(s) Piece
Datasheet 3005272 HARTING 09 66 221 7702 09662217702 Connector Number of pins: 15 Soldering 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3005272 HARTING 09 66 221 7702 09662217702 Connector Number of pins: 15 Soldering 1 pc(s) Piece
Description
Plug connector, shaft soldering connection, rated current 7.5 A, pin, size: D-Sub 2
