HARTING 09 67 015 0493 160 09670150493160 Shell Plastic 1 pc(s)
EAN:
Part number:
Item no:
Product type
Shell
Case material
Plastic
Content
1 pc(s)
Manufacturer part #
09670150493160
Width
40 mm
Datasheet (PDF)
Highlights & Details
Shell housing
- Plastic
Technical specifications
- Lock type: With long locking screws thread M3
- Net weight: 19 g
- Shielding: shielded
- Protection class according to IEC 60529:IP30
- Housing description: Cover can be screwed down
- Tightening torque: 0,25 Nm cable clamping screw;0,25 Nm cover screw;0,4 Nm locking screw
- Size D-Sub 2
- Housing type: Shell housing
- Design: Straight cable input
- Cable input 1x
- D-Sub case series
- Material housing: Plastic
- Surface of casing: Metallized
- Cable diameter: 3.3 ... 8.5 mm
- Length: 34.7 mm
- Width 40 mm
- Height: 15.2 mm
- 2-part: yes
- divisible: yes
- Ambient temperature: -20 ... +90 °C
- Cable fixing: Cable clip
- Product type
Shell
- Case material
Plastic
- Content
1 pc(s)
- Manufacturer part #
09670150493160
- Width
40 mm
- Height
15.2 mm
- Length
34.7 mm
- Type
09 67 015 0493 160
IP30
Screw
Straight
FALSE
Plastic
FALSE
Documents & Downloads
Datasheet
Datasheet 3005891 HARTING 09 67 015 0493 160 09670150493160 Shell Plastic 1 pc(s)
Datasheet 3005891 HARTING 09 67 015 0493 160 09670150493160 Shell Plastic 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3005891 HARTING 09 67 015 0493 160 09670150493160 Shell Plastic 1 pc(s)
Description
Shell housing, screw-in cover, size: D-Sub 2, with long locking screws thread M3, straight cable input, 1x
