HARTING 09062326858 Edge connector (sockets) No. of rows 3 1 pc(s)
EAN:
Part number:
Item no:
Product type
Edge connector (sockets)
Connector type
straight
CS
5.08 mm
Content
1 pc(s)
Total number of pins
32
Datasheet (PDF)
Highlights & Details
- Total number of pins 32
- No. of rows 3
- Content 1 pc(s)
Technical specifications
- Product type
Edge connector (sockets)
- Connector type
straight
- Total number of pins
32
- No. of rows
3
- CS
5.08 mm
- Connection
Soldering
- Factory colour
Pebble grey (RAL 7032)
- Case material
PA
- Manufacturer part #
09062326858
- Content
1 pc(s)
- Contact material
Copper alloy
- Type
09 06 232 6858
Printed circuit board to cable
Other
32
Other
-55-125 °C
Other
Soldering connection
Tin
3.7 mm
5.08 mm
3
3.81 mm
Thermoplastic
90° (upwards vertical)
Flange
6 A
