HARTING 09140033001XL Single module Han® C-Modul 3 Crimp 1 pc(s)
EAN:
Part number:
Item no:
Product type
Single module
Series
Han® C-Modul
Connection
Crimp
Total no. of pins
3
Core cross section (min.)
1.5 mm²
Datasheet (PDF)
Technical specifications
- Product type
Single module
- Factory colour
Pebble grey (RAL 7032)
- Series
Han® C-Modul
- Connection
Crimp
- Number of pins
3
- Total no. of pins
3
- Core cross section (min.)
1.5 mm²
- Core cross section (max.)
6 mm²
- Mating cycles
≥ 500
- Series
Han-Modular®
- Content
1 pc(s)
- Max. temperature
+125 °C
- Min. temperature
-40 °C
690 V
FALSE
3
Pin
-40-125 °C
V0
8 kV
Crimp connection
Other
3
TRUE
1.5-6 mm²
1.5-6 mm²
Other
Thermoplastic
40 A
Thermoplastic
500
3
