HARTING 09140203114 Pin inset 20 Crimp 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Pin inset
Connection
Crimp
Total no. of pins
20
Core cross section (min.)
0.09 mm²
Datasheet (PDF)
Technical specifications
- Connection type: Crimp connection
- Number of contacts: 20
- Rated current 4 A
- Temperature limit: -40 ... +85 °C
- Mating cycles ≥ 500
- Material application: Liquid-crystal polymer (LCP)
- Material flammability class acc. To UL 94: V-0
- Standards IEC 60664-1; IEC 61984
- Net weight: 30 g
- Rated voltage: 32 V
- Dimensioning surge voltage: 0.8 kV
- Pollution level 3
- Notes: With additional shield connection to joint frame; please order crimp contacts separately.
- Gender: Jack
- Conductor cross-section: 0.09 ... 0.52 mm²
- Description: HAN® Shielded module insert
- Further contacts: + shielding
- Material shielding: Zinc die-cast, nickel-plated
- Approvals DNV GL
- Constant resistance, shielding: ≤ 100 mΩ
- Packaging type
Piece
- Product type
Pin inset
- Features
+ shielding
- Connection
Crimp
- Number of pins
20
- Total no. of pins
20
- Core cross section (min.)
0.09 mm²
- Core cross section (max.)
0.52 mm²
- Mating cycles
≥ 500
- Content
1 pc(s)
- Max. temperature
+85 °C
- Min. temperature
-40 °C
32 V
FALSE
20
Bus
-40-85 °C
V0
0.8 kV
Crimp connection
Other
3
TRUE
0.09-0.52 mm²
0.09-0.52 mm²
Other
Thermoplastic
4 A
Thermoplastic
500
20
Documents & Downloads
Datasheet
Datasheet 3007485 HARTING 09140203114 Pin inset 20 Crimp 1 pc(s) Piece
Datasheet 3007485 HARTING 09140203114 Pin inset 20 Crimp 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3007485 HARTING 09140203114 Pin inset 20 Crimp 1 pc(s) Piece
Description
Crimp connection, socket, contacts: 20 + shielding, conductor cross-section: 0.09...0.52 mm², rated current: 4 A, liquid crystal polymer (LCP)
