HARTING 09170169622 PCB connector Contact spacing: 2.54 mm Total number of pins: 16 No. of rows: 2 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Connector type
straight
Product type
PCB connector
CS
2.54 mm
No. of rows
2
Datasheet (PDF)
Highlights & Details
Socket connector
- Total number of pins 16
- No. of rows 2
- Content 1 pc(s)
Technical specifications
- Series: SEK
- Component: Base connector
- Contact description: Straight
- Type of connection: Circuit board to cable
- Number of contacts: 16
- Plug contact series 2
- Pitch, connection side 2.54 mm
- Rated current 1 A
- Insulation resistance >1012 Ω
- Continuous resistance ≤ 20 mΩ
- Temperature limit: -40 ... +125 °C
- Test voltage Ueff 0.5 kV
- Material application: Thermoplastic molding material (PC)
- Colour insert: Beige
- Material flammability class acc. To UL 94: V-0
- IEC 60603-13 standard
- Net weight: 3 g
- Pitch, plug-side 1.27 mm
- Notes: For IDC flat cable with a 1.27 mm (0.050") pitch;AWG 28/7
- Packaging type
Piece
- Connector type
straight
- Product type
PCB connector
- CS
2.54 mm
- No. of rows
2
- Total number of pins
16
- Nominal current
1 A
- Content
1 pc(s)
- Type
09 17 016 9622
- Case material
Polycarbonate
- Manufacturer part #
09170169622
- Factory colour
Beige
- Insulation material
Polycarbonate
- Max. temperature
125 °C
- Min. temperature
-40 °C
- Resistance
≤ 20 mΩ
- Insulation resistance
1012 Ω
Printed circuit board to cable
Other
16
-40-125 °C
V0
Other
Other
2.54 mm
2
1.27 mm
Thermoplastic
90° (upwards vertical)
Other
1 A
Documents & Downloads
Datasheet
Datasheet 3001202 HARTING 09170169622 PCB connector Contact spacing: 2.54 mm Total number of pins: 16 No. of rows: 2 1 pc(s) Piece
Datasheet 3001202 HARTING 09170169622 PCB connector Contact spacing: 2.54 mm Total number of pins: 16 No. of rows: 2 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3001202 HARTING 09170169622 PCB connector Contact spacing: 2.54 mm Total number of pins: 16 No. of rows: 2 1 pc(s) Piece
Description
Socket connector, rated current 1 A, thermoplastic molding material (PC), beige, contacts: 16
