HARTING 09190109643 PCB connector + IDC Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 4 1 pc(s) Single
EAN:
Part number:
Item no:
Packaging type
Single
Connector type
straight
Product type
PCB connector
CS
2.54 mm
No. of rows
4
Datasheet (PDF)
Highlights & Details
Printed circuit board connector
- Total number of pins 10
- No. of rows 4
- Content 1 pc(s)
Technical specifications
- SEK low-profile
- Component: Circuit board connector
- Contact description: Straight
- Connection type: Solder connection;IDC terminals
- Type of connection: Circuit board to cable
- Number of contacts: 10
- Plug contact series 4
- Pitch, connection side 2.54 mm
- Rated current 1 A
- Insulation resistance >1012 Ω
- Continuous resistance ≤ 20 mΩ
- Temperature limit: -40 ... +125 °C
- Test voltage Ueff 0.5 kV
- Material application: Thermoplastic molding material (PC)
- Colour insert: Beige
- Material flammability class acc. To UL 94: V-0
- IEC 60603-13 standard
- Net weight: 3.68 g
- Pitch, plug-side 1.27 mm
- Notes: For IDC flat cable with a 1.27 mm (0.050") pitch;AWG 28/7
- Packaging type
Single
- Connector type
straight
- Product type
PCB connector
- Features
+ IDC
- CS
2.54 mm
- No. of rows
4
- Total number of pins
10
- Nominal current
1 A
- Content
1 pc(s)
- Connection
Soldering
Cut & Clip connector
- Type
09 19 010 9643
- Case material
PC
- Manufacturer part #
09190109643
- Factory colour
Beige
- Insulation material
PC
- Max. temperature
125 °C
- Min. temperature
-40 °C
- Resistance
≤ 20 mΩ
- Insulation resistance
1012 Ω
Printed circuit board to cable
Other
10
-40-125 °C
V0
Soldering connection
Other
2.54 mm
4
1.27 mm
Thermoplastic
90° (upwards vertical)
Other
1 A
Documents & Downloads
Datasheet
Datasheet 3000932 HARTING 09190109643 PCB connector + IDC Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 4 1 pc(s) Single
Datasheet 3000932 HARTING 09190109643 PCB connector + IDC Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 4 1 pc(s) Single
User & Safety Instructions
User & Safety Instructions 3000932 HARTING 09190109643 PCB connector + IDC Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 4 1 pc(s) Single
Description
PCB connector, solder connection, IDC insulation displacement connector, rated current 1 A, thermoplastic molded (PC), beige, contacts: 10
