HARTING 09451001720 Connector Han® 3A 12 Connector 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Connector
Series
Han® 3A
Connection
Connector
Total no. of pins
12
Datasheet (PDF)
Technical specifications
- RJ45 Hybrid series
- Component: Cable connector
- Number of contacts: 12
- Temperature limit: -40 ... +70 °C
- Mating cycles ≥ 500
- Net weight: 42.4 g
- Number of power contacts: 4
- Data rate: 10 Mbit/s; 100 Mbit/s; 1 Gbit/s; 2.5 Gbit/s; 5 Gbit/s; 10 Gbit/s
- Conductor cross-section: AWG 28 ... AWG 24 data;AWG 16 Power
- Shielding: Fully shielded, 360° shield contact
- Transmission features: Cat. 6A class EA to 500 MHz
- PROFINET: Yes
- Design size 3 A
- Approvals DNV GL
- Rated current (Power) 16 A.
- Rated voltage (data): 50 V AC; 60 V DC
- Rated voltage (Power): 48 V DC
- Rated current Data 1.76 A
- Number of data contacts: 8
- Wire outer diameter: 1 mm
- Packaging type
Piece
- Product type
Connector
- Series
Han® 3A
- Features
+ shielding
- Connection
Connector
- Number of pins
12
- Total no. of pins
12
- Core cross section (min.)
0.08 mm²
- Core cross section (max.)
1.5 mm²
- Core cross section power contact (min.)
1.5 mm²
- Core cross section power contact (max.)
1.5 mm²
- Mating cycles
≥ 500
- Series
RJ45 Hybrid
- Content
1 pc(s)
- Max. temperature
+70 °C
- Min. temperature
-40 °C
FALSE
12
Other
-40-70 °C
Other
Other
Other
FALSE
0.08-0.22 mm²
0.08-0.22 mm²
Other
Other
Other
500
12
Documents & Downloads
Datasheet
Datasheet 3011321 HARTING 09451001720 Connector Han® 3A 12 Connector 1 pc(s) Piece
Datasheet 3011321 HARTING 09451001720 Connector Han® 3A 12 Connector 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3011321 HARTING 09451001720 Connector Han® 3A 12 Connector 1 pc(s) Piece
Description
Connector, cable connector, size: HAN 3 A, contacts: 12, conductor cross-section: 0.08...0.22 mm² Data 1.5 mm² Power
