HARTING 14031416101000 Print terminal Number of pins 14 Green 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Print terminal
CS
5 mm
Pins per row
14
Number of pins
14
Datasheet (PDF)
Highlights & Details
PCB terminal
- Content 1 pc(s)
Technical specifications
- Range: Har-flexicon®
- Component: Print terminal
- Connection type: Push-in spring-force connection;wave soldering connection
- Type of connection: Circuit board to cable
- Number of contacts: 14
- Plug contact series 1
- Pitch, connection side 5 mm
- Rated current 12 A
- Temperature limit: -40 ... +110 °C
- Insulation material group I (600 ≤ CTI)
- Material application: Polyamide (PA)
- Colour insert: Green
- Material contacts: Copper alloy
- Contact surface: Sn over Ni connectors side; Sn over Ni connection side
- Material flammability class acc. To UL 94: V-0
- Rated voltage: 300 V
- Dimensioning surge voltage: 4 kV
- Pollution level 3
- Conductor cross-section: AWG 30 ... AWG 12
- Stripped length: 10 mm
- Description: Vertical
- UKCA approved
- Packaging type
Piece
- Type
14 03 141 6101 000
- Product type
Print terminal
- Features
+ push-in spring bracket
- CS
5 mm
- No. of rows
1
- Pins per row
14
- Number of pins
14
- Min. stripping length
10 mm
- Stripping length (max.)
10 mm
- Connection
Push-in spring-loaded terminal
- Nominal current
12 A
- Nominal current - rounded value
12 A
- AWG (min.)
30
- Connector orientation
Perpendicular (to the PCB)
- AWG max.
12
- Contact material
Copper alloy
- Enclosure material
Polyamide
- Factory colour
Green
- Manufacturer part #
14031416101000
- Content
1 pc(s)
- Nominal voltage
300 V
Printed circuit board to cable
Other
300 V
14
Other
-40-110 °C
Other
4 kV
Soldering connection
Tin
5 mm
1
Polyamide (PA)
Other
Other
12 A
Documents & Downloads
Datasheet
Datasheet 3008860 HARTING 14031416101000 Print terminal Number of pins 14 Green 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3008860 HARTING 14031416101000 Print terminal Number of pins 14 Green 1 pc(s) Piece
Description
PCB terminal, vertical push-in spring force connection, rated current 12 A, contacts: 14, copper alloy
