HARTING 21033211802 PCB adapter straight Total number of pins: 8 1 pc(s)
EAN:
Part number:
Item no:
Product type
PCB adapter
Connector type
straight
Total no. of pins
8
Connection
SMT
Content
1 pc(s)
Datasheet (PDF)
Technical specifications
- Series: Circular connector M12
- Component: Circuit board adapter
- Connection type: Reflow soldering connection (SMT)
- Number of contacts: 8
- Rated current 2 A
- Insulation resistance >108 Ω
- Continuous resistance ≤ 10 mΩ
- Temperature limit: -40 ... +85 °C
- Mating cycles ≥ 100
- Insulation material group I (600 ≤ CTI)
- Material application: Liquid-crystal polymer (LCP)
- Material contacts: Copper alloy
- Contact surface: Au over Ni on plug side
- Material flammability class acc. To UL 94: V-0
- IEC 61076-2-101 standard
- Net weight: 3.4 g
- Rated voltage: 30 V
- Pollution level 3
- Note: Flange socket order separately.
- Coding: A-coding
- Gender: Pen
- Description: Straight
- Shielding: shielded
- Over voltage category III
- Type
21 03 321 1802
- Product type
PCB adapter
- Connector type
straight
- Total no. of pins
8
- Connection
SMT
- Content
1 pc(s)
- Max. temperature
+85 °C
- Min. temperature
-40 °C
- Contact material
Copper alloy
- Weight
3.4 g
- Manufacturer part #
21033211802
- Insulation material
Liquid crystal polymer
- Number of pins
8
- Feature
shielded
Other
30 V
8
Pin
-40-85 °C
Other
Soldering connection
Nickel/gold
III
Liquid crystal polymer
Other
Other
2 A
Documents & Downloads
Datasheet
Datasheet 3008587 HARTING 21033211802 PCB adapter straight Total number of pins: 8 1 pc(s)
Datasheet 3008587 HARTING 21033211802 PCB adapter straight Total number of pins: 8 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3008587 HARTING 21033211802 PCB adapter straight Total number of pins: 8 1 pc(s)
Description
PCB adapter, straight, reflow soldering connection (SMT), rated current 2 A, contacts: 8, Copper alloy, Au over Ni plug side
