HARTING 21033213501 PCB adapter Total number of pins: 5 1 pc(s)
EAN:
Part number:
Item no:
Product type
PCB adapter
Total no. of pins
5
Connection
Soldering
Content
1 pc(s)
Type
21 03 321 3501
Datasheet (PDF)
Technical specifications
- Series: Circular connector M12
- Component: Circuit board adapter
- Connection type: Shaft soldering connection
- Number of contacts: 5
- Type of locking: Screw lock
- Rated current 4 A
- Insulation resistance >108 Ω
- Temperature limit: -40 ... +85 °C
- Mating cycles ≥ 100
- Material application: Polyamide (PA)
- Material contacts: Copper alloy
- Contact surface: Au over Ni on plug side
- Material flammability class acc. To UL 94: V-0
- IEC 61076-2-101 standard
- Net weight: 14.2 g
- Rated voltage: 60 V
- Pollution level 3
- Coding: A-coding
- Gender: Pen
- Description: Angled;for rear wall mounting
- Shielding: shielded
- Protection class according to IEC 60529: IP67 when connected
- Tightening torque 1 Nm counter nut
- Material housing: Copper zinc alloy
- Type
21 03 321 3501
- Product type
PCB adapter
- Total no. of pins
5
- Connection
Soldering
- Content
1 pc(s)
- Max. temperature
+85 °C
- Min. temperature
-40 °C
- Seal
Screw-type locking
- Contact material
Copper alloy
- Case material
Copper alloy, zinc plated
- Weight
14.2 g
- Manufacturer part #
21033213501
- Insulation material
Polyamide
- Number of pins
5
- Feature
shielded
Other
60 V
5
Pin
-40-85 °C
Other
Soldering connection
Nickel/gold
Polyamide (PA)
Other
Other
4 A
Documents & Downloads
Datasheet
Datasheet 3008624 HARTING 21033213501 PCB adapter Total number of pins: 5 1 pc(s)
Datasheet 3008624 HARTING 21033213501 PCB adapter Total number of pins: 5 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3008624 HARTING 21033213501 PCB adapter Total number of pins: 5 1 pc(s)
Description
PCB adapter, angled, for rear wall mounting, shaft soldering connection, rated current 4 A, Contacts: 5, copper alloy, Au over Ni plug side
