Hekatron Hub mains-powered
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Rated voltage: 230 V/AC
- Nominal frequency 50/60 Hz
- Power consumption 13.8 VA
- Output voltage 24 V DC
- Output current: max. 400 mA
- Alarm relay 1 changeover, potential-free
- Switching capacity
- MAX. 250 V/AC/5A
- max. 30V DC / 3A
- max. 24V DC / 5A
- Operating temperature -30 °C to +50 °C
- Storage temperature -30 °C to +60 °C.
- Protection class during cable entry Wall mounting: IP65
- Protection class during cable entry flush:IP30
- Product type
Hub
- Power supply (LOV)
mains-powered
- Content
1 pc(s)
- Weight
420 g
- Type
With housing
Documents & Downloads
Datasheet
Datasheet 3818989 Hekatron Hub mains-powered
User & Safety Instructions
User & Safety Instructions 3818989 Hekatron Hub mains-powered
User & Safety Instructions 3818989 Hekatron Hub mains-powered
Description
Suitable for use at doors and gates in various application areas of industrial to administrative buildings
The FSZ Basis from Hekatron is a central locking system that meets the requirements of DIN EN 14637 in addition to the DIBt test bases.
Product properties
The FSZ base is power supply, control, manual button, alarm memory and reset button in one
DIN EN 14637 and DIBt compliant, state of the art technology
Technically compatible with predecessor products and cable networks
Other features
Optional line monitoring in accordance with DIN EN 14637 (no line monitoring in Ex applications)
Alarm storage
Separate alarm outputs for individual control options
Cable guides above, below and rear
Easily accessible connection terminals
Can be used in difficult ambient conditions with humidity, dust, heat, cold and temperatures from -10° to +50°C.
Short-circuit protected
Technically compatible with all previous products and existing cable networks
Removable labels
