Helios Ventilatoren 1032 Axial fan 0 V 10560 m³/h 630 mm
EAN:
Part number:
Item no:
Technical specifications
- Mains frequency 50 Hz
- Rated voltage: 400 V
- Medium temperature: -30..60°C
- Volume flow 10560 m³/h
- Speed 960 1 rpm
- Protection class (IP) IP55
- Design: Ventilation and ventilation
- Nominal width 630 mm
- Shutter flap: Without
- Product type
Axial fan
- Nominal voltage
0 V
- Rotational speed
960 U/min
- Air flow rate
10560 m³/h
- Suitable for pipe Ø
630 mm
- Ventilation features
Adjustable
IP55
- Material
Steel
- Type
Ventilation
- Operating voltage
0 V
- Max. temperature
60 °C
- Min. temperature
-30 °C
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3161345 Helios Ventilatoren 1032 Axial fan 0 V 10560 m³/h 630 mm
Description
Axial high-performance fan with wall mounting ring, influx nozzle, directly driven. Wall ring made of galvanized sheet steel, double painted, papyrus white color, nozzle with protective grille at the suction side. Connection box on the motor. Wheel with 7 GRP blades, hub made of galvanized steel plate, wing position continuously adjustable from outside in a standstill, with Hohem efficiency, balance quality G 6.3 according to VDI 2060 Three-phase short-circuit motors controlled by voltage reduction Speed, thermal contacts, closed design, maintenance-free, sealed, Low-noise ball-bearing with long-term lubrication.
