Helios Ventilatoren 383 In-line extractor 400 V 12130 m³/h 560 mm
EAN:
Part number:
Item no:
Technical specifications
- Material of housing: Steel, treated
- Air quantity unloaded: 12130 m³/h.
- Connection voltage 400 V
- Power consumption 0.92 kW
- With thermal protection: Yes
- DC motor: No.
- Indirect drive: No.
- Electrical connection: Connection terminals
- Protection class (IP) IP55
- Max. Air temperature 60°C.
- 2 speed engine: Yes
- Suitable for electronic control: Yes
- Suitable for frequency control: No.
- Suitable for low current control: No.
- Suitable for transformer control: Yes
- Pole reversal selectable: Yes
- Length: 500 mm
- Diameter of housing 640 mm
- Channel diameter 560 mm
- Connection: Flange
- Product type
In-line extractor
- Nominal voltage
400 V
- Current consumption
920 W
920 W
- Air flow rate
12130 m³/h
- Ventilation features
Adjustable
- Suitable for pipe Ø
560 mm
IP55
- Material
Steel
- Dim
(Ø x L) 560 mm x 500.00 mm
- Length
500.00 mm
- Depth
500 mm
- (Ø)
560 mm
- Operating voltage
400 V
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3161792 Helios Ventilatoren 383 In-line extractor 400 V 12130 m³/h 560 mm
Description
Axial high-power fan cylindrical tube shell, two-sided flanges, directly driven. Cylindrical tube made of galvanized steel plate, surrounded with impeller, formed flange on both sides, hole pattern according to DIN 24155. With external terminal box. Wheel with 7 GRP blades, hub made of galvanized steel plate, wing position continuously adjustable from outside in a standstill, with Hohem efficiency, balance quality G 6.3 according to VDI 2060 Three-phase short-circuit motors, with dahland winding (pole-selectable), closed design, maintenance-free, sealed, Low-noise ball-bearing with long-term lubrication.
