Helios Ventilatoren HQD 355/6 TK Axial fan 400 V 1970 m³/h
EAN:
Part number:
Item no:
Technical specifications
- Design: Ventilation
- Conveying medium temperature: -30..60 °C.
- Nominal diameter 355 mm
- Mains frequency 50 Hz
- Product type
Axial fan
- Nominal voltage
400 V
- Rotational speed
960 U/min
- Air flow rate
1970 m³/h
IP55
- Factory colour
White
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2292428 Helios Ventilatoren HQD 355/6 TK Axial fan 400 V 1970 m³/h
Description
Axial high-performance fan with square mounting plate, inlet nozzle, directly driven. Square mounting plate with molded nozzle made of galvanized sheet steel, double painted, color papyrus white. Impeller with 7 thermoplastic blades. High efficiency, low operating noise. Vibration-free running through dynamic balancing according to quality grade G 6.3 VDI 2060 and DIN ISO 1940. Three-phase short-circuit rotor motor through voltage reduction Speed controllable, thermal contacts, closed design, maintenance-free, sealed, low-noise ball bearings with long-term lubrication.
