HELU Industrial LED indicator light HELULIGHT® STATIC-RGBW 560 RGBW 28.2 W 100 ° (L x W x H) 635 x 30 x 17.50 mm 1 pc(s)
EAN:
Part number:
Item no:
Product type
Industrial LED indicator light
Power
28.2 W
IP rating
IP40
Energy efficiency rating
n.rel.
Type
HELULIGHT® STATIC-RGBW 560
Datasheet (PDF)
Technical specifications
- Colour of housing: Anodised natural
- Material cover: PMMA
- Cover: Diffuse
- Variant connection: Flange, built-in connection socket
- Connection number of pins: 5
- Coding: B coded
- Looped through: No.
- Mounting: Rigid
- Illuminated length 560 mm
- Hole spacing
- : 623 mm.
- Product weight without packaging (g): 422
- Color fidelity CRI: 80
- Max. Illumination level 465
- Light current white 1502
- Luminous flux, red: 215
- Green luminous flux: 541
- Luminous flux Blue: 156
- Output white 11.4 W
- Power red 6.2 W
- Power green 5.2 W
- Output blue 5.2 W
- Dimmable: External PWM
- Lamp life 60,000 h
- Surface temperature lamp: Label D.
- Product type
Industrial LED indicator light
- Type
HELULIGHT® STATIC-RGBW 560
- LED features
dimmable
- Max. operating voltage
24 V DC
- Operating voltage
24 V DC (max)
28.2 W
- Factory colour
RGBW
- Colour temperature (max.)
5700 K
- Radiation angle
100°
- Connection
M8 plug
- Material
Aluminium
IP40
- Protection class
III
- Min. temperature
-20 °C
- Max. temperature
50 °C
- Length
635 mm
- Width
30 mm
- Height
17.50 mm
- Dim
(L x W x H) 635 x 30 x 17.50 mm
- RoHS-compliant
Yes
n.rel.
