HT Instruments HT9015 Clamp meter Digital CAT III 1000 V, CAT IV 600 V Display (counts): 6000
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
HT9015
- CAT III 1000 V, CAT IV 600 V
Technical specifications
- Voltage reading range DC (min.)
0.01 mV
- Product type
Clamp meter
- Voltage DC reading range (max.)
1000 V
- V AC reading range (min.)
1 mV
- V AC reading range (max.)
1000 V
- Amperage reading range DC (min.)
0.01 A
- A DC reading range (max.)
600 A
- A AC reading range (min.)
0.01 A
- Amperage reading range AC (max.)
600 A
- Reading range - resistance
0.1 Ω - 60 MΩ
- Reading range - capacity
0.01 nF - 4 mF
- Frequency reading range
0.01 Hz - 60 kHz
- Temperature
-20 to +760 °C
- Measurement type (details)
True RMS
- Height
45 mm
- Width
75 mm
- Length
210 mm
- Weight
400 g
Manufacturer's standards (no certificate)
- Reading category
CAT III 1000 V
CAT IV 600 V
- Voltage metering
AC/DC
- Current reading
AC/DC
- Type
HT9015
- Display
Digital
- Display (counts)
6000
- Dim
(L x W x H) 210 x 75 x 45 mm
- Opening range of current clamps
30 mm
Variants(All information is without VAT, plus shipping costs)
Calibrated to
HT Instruments HT9015 Clamp meter Digital CAT III 1000 V, CAT IV 600 V Display (counts): 6000
This article
Manufacturer's standards (no certificate)
Minimum order quantity: 1
Multiple: 1
€ 264.71*
HT Instruments HT9015 Clamp meter Calibrated to (ISO standards) Digital CAT III 1000 V, CAT IV 600 V Display (counts): 6000
ISO standards
Minimum order quantity: 1
Multiple: 1
HT Instruments HT9015 Clamp meter Calibrated to (DAkkS standards) Digital CAT III 1000 V, CAT IV 600 V Display (counts): 6000
DAkkS standards
Minimum order quantity: 1
Multiple: 1
HT Instruments HT9015 Clamp meter Calibrated to (ISO standards) Digital CAT III 1000 V, CAT IV 600 V Display (counts): 6000
ISO standards
Minimum order quantity: 1
Multiple: 1
HT Instruments HT9015 Clamp meter Calibrated to (DAkkS standards) Digital CAT III 1000 V, CAT IV 600 V Display (counts): 6000
DAkkS standards
Minimum order quantity: 1
Multiple: 1
Documents & Downloads
Datasheet
Datasheet 2176475 HT Instruments HT9015 Clamp meter Digital CAT III 1000 V, CAT IV 600 V Display (counts): 6000
User & Safety Instructions
User & Safety Instructions 2176475 HT Instruments HT9015 Clamp meter Digital CAT III 1000 V, CAT IV 600 V Display (counts): 6000
Description
The professional clip-on ammeter HT9015 was developed to measure direct and alternating currents up to 600 A in the overvoltage category CAT IV 600 V or CAT III 1000 V and to comply with the specifications of IEC/EN 61010-1. This TRMS measuring clamp-on ammeter is equipped with a large 6000 point resolution display and an Auto Power OFF function, in order to protect the batteries. The HT9015 also offers a variety of multimeter measurement functions with a wide measurement range.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Test lead pair
- K-type wire probe + adapter
- 9 V battery
- Bag
- User manual.
