VOLTCRAFT VC-44 Handheld multimeter Digital CAT III 1000 V Display (counts): 20000

Two-in-one: Hand-held multimeter with basic oscilloscope
The VOLTCRAFT VC-44 combines the functions of a digital multimeter and an oscilloscope in a compact housing. With CAT III 1000 V safety evaluation, the VC-44 is designed for work in building installations at a voltage of up to 1000 volts. The combination of the two measuring instruments makes the measuring device a versatile tool for electricians, technicians and service personnel.
DMM functions
The VC-44 VOLTCRAFT has a high display resolution of 20,000 counts and True RMS, WAS enables accurate measurements of AC voltages and currents, even on non-sinusoidal signals. It covers all common DMM functions, including AC/DC voltage, AC/DC current, resistance, capacitance, Frequency and pulse duty factor. In addition, the device offers diode measurement and intelligent sensor detection.
Oscilloscope functions
The integrated oscilloscope with 1 channel has an analogue bandwidth and enables real-time sampling. Automatic signal curve measurement as well as the automatic measurement of Vmax, Vmin, Vss, Vavg, Veff and frequency simplify the quick analysis of signals. The trigger functions Auto, Normal and Single as well as the possibility of automatic setting of time base, vertical amplitude and trigger value simplify the operation.
Ease of use and protection
The 7.11 cm (2.8 inch) IPS LCD display with backlight provides clear and easy-to-read measurement results and signal shapes even in badly lit environments. The VC-44 has a robust input protection, which protects it against over-voltages. The battery warning indicator informs in time about a low charging status and the standby mode contributes to energy efficiency.
Supplied with accessories
Included in the delivery are the measuring device itself, a pair of test probes, a USB-cable, a convenient carry bag for the safe transportation and a detailed user manual.

This text is machine translated.
