Image similar
ifm Electronic Clinometer JD1311 JD1311 Reading range: 0 - 360 ° CAN M12
Product type
Clinometer
Max. operating voltage
30 V DC
Reading range (max.)
360 °
Connector
M12
Type
JD1311
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Clinometer
- Type
JD1311
- Min. operating voltage
9 V DC
- Max. operating voltage
30 V DC
- Operating voltage
9 - 30 V DC
- Reading range (min.)
0°
- Reading range (max.)
360°
- Reading range
0 - 360 °
- Resolution
0.01°
- No. of axles
1
- Accuracy ±
0.3°
- Connector
M12
- Interfaces
CAN
- Min. temperature
-40 °C
- Max. temperature
85 °C
- RoHS-compliant
Yes
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3321803 ifm Electronic Clinometer JD1311 JD1311 Reading range: 0 - 360 ° CAN M12
User & Safety Instructions
User & Safety Instructions 3321803 ifm Electronic Clinometer JD1311 JD1311 Reading range: 0 - 360 ° CAN M12
