ifm Electronic Sensor Inductive IA5122 IA5122 non-shielded PNP, NPN (Ø x L) 20 mm x 92 mm
Product type
Sensor
Max. operating voltage
55 V DC
Contact type
1 breaker
1 maker
Switching distance (max.)
10 mm
Outputs
PNP
NPN
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Sensor
- Type
IA5122
- Min. operating voltage
10 V DC
- Max. operating voltage
55 V DC
- Operating voltage
10 - 55 V DC
- Contact type
1 breaker
1 maker
- Switching distance (max.)
10 mm
- Outputs
PNP
NPN
- Enclosure material
Plastic
- Model
Inductive
- Installation type
non-shielded
- Connector
Clip
- Features
acid-resistant
- Min. temperature
-25 °C
- Max. temperature
80 °C
- Length
92 mm
- (Ø)
20 mm
- Dim
(Ø x L) 20 mm x 92 mm
- Content
1 pc(s)
- Switching frequency
300 Hz
- UKCA
yes
