Name: ifm Electronic Sensor Inductive IG5554 IG5554 M18 x 1 shielded PNP
Brand: ifm Electronic
SKU: 3317858

Metal screw and nut in close-up, meticulously rendered, showing threads for mechanical fastenings.

Image similar

Product type

Sensor

Max. operating voltage

30 V DC

Contact type

1 maker

Switching distance (max.)

5 mm

Outputs

PNP

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Ifm IG5554 Inductive Sensor

Robust metal casing for use in harsh industrial environments
High operating temperature range
High protection class to meet the requirements of harsh industrial ambient

Technical specifications

Dimensions [mm]: M18 x 1 / L = 80
Display: Switch status 4 x 90° LED, yellow
Working distance [mm]: 0...4.05
Ambient temperature-1 [°C]: -25...80
Output function: Closer
Special feature: Gold-plated contacts
Operating voltage [V]: 10... 30 DC
Continuous current carrying capacity of the switching output DC [mA]: 200
Flush mounting type: Flush mounting
Electrical version: PNP
Embedded software included: No.
Housing: Threaded design
Weight [g]: 56,500
Thread name M18 x 1
Hysteresis: 3...15
Correction factor (Al): 0.4
Correction factor (Cu): 0.3
Correction factor (Ms): 0.5
Correction factor (V2A) 0.7
Correction factor steel (St37): 1
Short-circuit protection: Yes
max. Voltage drop switch output DC [V]: 2.5
MTTF: 1083
Test mark (special cases): CCC
Real switching distance Sr [mm]: 5 ± 10 %
Switching distance [mm]: 5
Switching frequency DC [Hz]: 500
Switch point drift: -10...10
IP 67 protection
Protection class: II
Plug connection: Plug - pin layout: 0061 - plug connection: 1 x M12; coding: A; contacts: Gold-plated
Current consumption: < 10
Overload-proof: Yes
Reverse polarity protection: Yes

Product type: Sensor

Type: IG5554

Min. operating voltage: 10 V DC

Max. operating voltage: 30 V DC

Operating voltage: 10 - 30 V DC

Contact type: 1 maker

Switching distance (max.): 5 mm

Outputs: PNP

Enclosure material: Metal

Model: Inductive

Installation type: shielded

Size: M18 x 1

Connector: M12

Min. temperature: -25 °C

Max. temperature: 80 °C

Length: 80 mm

Content: 1 pc(s)

Switching frequency: 500 Hz

UKCA: yes
