Image similar
ifm Electronic Sensor Inductive IT5039 IT5039 6.5 mm shielded PNP (Ø x L) 6.5 mm x 19 mm
Product type
Sensor
Max. operating voltage
30 V DC
Contact type
1 maker
Switching distance (max.)
2 mm
Outputs
PNP
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Ifm IT5039 Inductive sensor
- Special short design
- For use in narrow installation spaces
- Space-saving connection technology through cable outlet on the side
- Robust metal casing for use in harsh industrial environments
- Very high switching frequency
Technical specifications
- Dimensions [mm]: Ø 6.5 / L = 19
- Working distance [mm]: 0...1.6
- Ambient temperature-1 [°C]: -25...70
- Short-circuit protection version: Synchronised
- Output function: Closer
- Operating voltage [V]: 10... 30 DC
- Continuous current carrying capacity of the switching output DC [mA]: 200
- Flush mounting type: Flush mounting
- Electrical version: PNP
- Cylindrical housing
- Weight [g]: 57,000
- Hysteresis: < 15
- Cable: 2 m, PVC; 3 x 0.14 mm²
- Correction factor (Al): 0.3
- Correction factor (Cu): 0.2
- Correction factor (Ms): 0.4
- Correction factor (V2A) 0.7
- Correction factor steel (St37): 1
- Short-circuit protection: Yes
- max. Voltage drop switch output DC [V]: 2.5
- MTTF: 1045
- Test mark (special cases): CCC
- Real switching distance Sr [mm]: 2 ± 10 %
- Switching distance [mm]: 2
- Switching frequency DC [Hz]: 1000
- Switch point drift: -10...10
- IP 67 protection
- Power consumption 20; (24 V)
- Overload-proof: No.
- Reverse polarity protection: Yes
- Product type
Sensor
- Type
IT5039
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Contact type
1 maker
- Switching distance (max.)
2 mm
- Outputs
PNP
- Enclosure material
Metal
- Model
Inductive
- Installation type
shielded
- Size
6.5 mm
- Connector
Cable, open end
- Cable length
2 m
- Min. temperature
-25 °C
- Max. temperature
70 °C
- Length
19 mm
- (Ø)
6.5 mm
- Dim
(Ø x L) 6.5 mm x 19 mm
- Content
1 pc(s)
- Switching frequency
1000 Hz
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3318865 ifm Electronic Sensor Inductive IT5039 IT5039 6.5 mm shielded PNP (Ø x L) 6.5 mm x 19 mm
User & Safety Instructions
User & Safety Instructions 3318865 ifm Electronic Sensor Inductive IT5039 IT5039 6.5 mm shielded PNP (Ø x L) 6.5 mm x 19 mm
Description
Ifm IT5039 Inductive sensor
