ifm Electronic SN2303 Flow meter signal processor SN2303 1 pc(s)
EAN:
Part number:
Item no:
Product type
Flow meter signal processor
Type
SN2303
Max. operating voltage
200 V AC
Operating voltage
200 V AC (max)
Content
1 pc(s)
Datasheet (PDF)
Highlights & Details
Ifm SN2303 Flow Sensor Evaluation Unit
- For applications in areas where there is a risk of explosion
- Integrated flow and line monitoring
- Intuitive adjustment of switch point and Medium
- For connecting flow sensors in intrinsically safe design
- Easy to read multi-color LED bar graph display
Technical specifications
- Dimensions [mm] 78 x 45 x 120
- Number of channels: 1
- Display: Function: 11 x LED; switch status: LED, red
- Fault switching point adjustment: Potentiometer
- Ambient temperature-1 [°C]: -20...60
- Application: Flow monitoring; line monitoring
- ATEX Device Identification: II (1) G [Ex ia Ga] IIC
- Range selection liquid / gaseous: Slide switches
- Standby delay time [s]: 30
- Operating voltage [V]: < 200 AC
- Operating voltage tolerance [%]: -10...10
- Electrical version: Relay
- Required fuse: Miniature fuse in accordance with IEC60127-2 Sheet 1; ≤ 5 A; quick-acting; place the fuse outside the hazardous area.
- Frequency AC [Hz]: 47...63
- Housing: Terminal rail housing
- Weight [g]: 548,500
- Connection/terminals ready for assembly: Terminals: 15 x ...2.5 mm²
- CONTACT RATING: 4 A (250 V AC COS PHI > 0.7) ; 0.2 A (250 V DC); 4 A (24 V DC)
- Short-circuit-proof: No.
- Storage temperature [°C]: -20...85
- Max. Power consumption [VA]: 5
- MTTF: 248
- Switching function line monitoring: The relay switches off in the case of a wire break
- Switching function flow monitoring: The relay attracts in case of flow
- IP 40 protection
- Protection class IP 20 terminals
- Overload-proof: No.
- Reverse polarity protected: No.
- APPROVALS: PTB 01 ATEX 2075; TIIS TC16593
- Product type
Flow meter signal processor
- Type
SN2303
- Max. operating voltage
200 V AC
- Operating voltage
200 V AC (max)
- Content
1 pc(s)
- RoHS-compliant
Yes
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3321796 ifm Electronic SN2303 Flow meter signal processor SN2303 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3321796 ifm Electronic SN2303 Flow meter signal processor SN2303 1 pc(s)
