Iiyama Zubehör SlotPC Modul OPC51204BC-1 PC module
EAN:
Part number:
Item no:
Technical specifications
- Processor generation: Intel® Core™ i5 processors of the 12. Generation
- Internal memory type DDR4 SDRAM
- Optical Drive Type: No.
- SSD interface PCI Express
- SSD form factor M.2
- Built-in graphics card model: Intel® UHD Graphics
- Product type: Mini PC
- WLAN standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
- HDMI version 2.0
- Installed operating system: Windows® 11 IoT Enterprise
- Product type
PC module
- Factory colour
Black
- Dim
(W x H x D) 119 x 30 x 180 mm
- Width
119 mm
- Height
30 mm
- Depth
180 mm
- Weight
600 g
- Bluetooth
5.2
- Bluetooth
Yes
- No. of DisplayPort
1 x
- No. of HDMI ports
1 x
- Processor cores (No.)
8 x
- No. of USB type A 3.1 / 3.2 1st Gen
4 x
- Keyboard layout
Keyboard not included
- Dedicated graphics card
No
- Onboard graphics card
Yes
- Onboard graphics card (GPU manufacturer)
Intel
- CPU series
Intel® Core™ i5
- Memory capacity
256 GB
- Memory clock speed
3200 MHz
- 10/100/1000 Mbps ports
1 x
- Power consumption (standby)
2.9 W
- Power consumption (ON)
80.7 W
8 GB
- RAM / Max. upgrade
32 MB
- SSD
256 GB
- Onboard graphics card (version)
Intel® UHD graphics card
- Processor/type
i5-12450H
- Wi-Fi
Yes
- CPU cache
12 MB
- UKCA
yes
- Operating temperature (T-T)
0 - 45 °C
- Ethernet LAN
yes
- Storage relative humidity (H-H)
10 - 95 %
- Display included
no
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
- Headphone outputs
1
- Microphone in
yes
- Trusted Platform Module (TPM)
yes
- Efficient cores
4
- Performance cores
4
- Processor base power
45 W
- Maximum turbo power
95 W
- Efficient-core Max Turbo Frequency
3.3 GHz
- Performance-core Max Turbo Frequency
4.4 GHz
- Operating relative humidity (H-H)
10 - 95 %
- Storage temperature (T-T)
-10 - 50 °C
- Package weight
957 g
- Number of SSDs installed
1
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3796674 Iiyama Zubehör SlotPC Modul OPC51204BC-1 PC module
Description
This OPS SLOT PC transforms your interactive Iiyama display into a stand-alone solution. It comes with a powerful Intel® Core i5 processor with built-in Ultra HD graphics and a fast SSD drive. No more cables to get around and install a PC on the back of the monitor or on a floor lift. The OPC51204BC-1 is also very quiet with a noise level of less than 34dB at 100% CPU load at 1 meters distance. Simply insert the Iiyama OPS-SLOT PC and start immediately.
This text is machine translated.
This text is machine translated.
Hints
HDMI is a registered trademark of HDMI Licensing, LLC. The “CI Plus” Logo is a trademark of CI Plus LLP. All information provided is subject to change without notice. Design and functions are subject to change
