IMG Stageline TXS-900HSE Radio transmitter
EAN:
Part number:
Item no:
Highlights & Details
IMG Stage Line TXS-900HSE microphone transmitter
- 2 frequency ranges
- SYNC-function for the synchronisation with the receivers TXS-900 and TXS-920
- This text is machine translated.
Technical specifications
- Carrier frequency: 823-832 MHz+ 863-865 MHz
- Transmitted power 10 mW
- Audio frequency range:80-1 8000 Hz
- Frequency stability: +/0.005%
- Operating duration:> 15 h
- Dimensions 65 x 110 x 25 mm
- Weight: 90 g
- Product type
Radio transmitter
- Factory colour
Black
- Dim
(L x W x H) 25 x 65 x 110 mm
- Weight
90 g
- Length
25 mm
- Width
65 mm
- Height
110 mm
- No. of frequencies (adjustable)
2
- Height (min.)
110 mm
- Depth
25 mm
- Interfaces
Mic XLR in
- No. of microphone XLR inputs
1 x
- Transmission frequency
823-832 MHz + 863-865 MHz MHz
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1332931 IMG Stageline TXS-900HSE Radio transmitter
Description
Features
- Multi-frequency pocket transmitter with UHF PLL technology.
- 2 frequency ranges (E-Band: 823-832 MHz and 863-865 MHz)
- SYNC-function for the synchronisation with the receivers TXS-900 and TXS-920
- Mute function
- Sensitivity adjustable in 3 settings
- LCD display for channel and battery status
- Suitable for combination with head/Ear Microphones and ties microphones with 3-pole mini XLR-connection
- Belt clip
- Power supply via 2 x 1.5 V AA battery (not included).
- Free registration and in the EU.
Scope of delivery
- Belt clip.
