Jamicon Electrolytic capacitor Radial lead 2 mm 47 µF 25 V 20 % (Ø x H) 5 mm x 11.0 mm 1 pc(s) Tape
Packaging type
Tape
Product type
Electrolytic capacitor
Type
Radial lead
Capacity (elec.)
47 µF
Nominal voltage
25 V
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
Jamicon Elko 47uF 25V 5x11mm RM2 belt
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series TL
- Design_1: Radial
- Applications: Suitable for EVG, adapter and switched-mode power supply
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: THT
- Delivery form_1: Taped
- Connections_1: 2-pin
- Characteristics_1: Low impedance and long life with a continuous load of 5000 hours.
- Wire diameter 0.5 mm.
- Pitch_1:2 mm
- Capacity 47 µF
- Capacity_1: 47
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.14
- Leakage current 3 µA
- Ripple current 0.19 mA
- Equivalent Series Resistance (ESR): 0.539 ohms
- Nominal voltage DC 25 V
- Surge voltage 32 V
- Lifetime_1: 2,000 h
- Packaging type
Tape
- Product type
Electrolytic capacitor
- Type
Radial lead
- CS
2 mm
- Dim
(Ø x H) 5 mm x 11.0 mm
- Capacity (elec.)
47 µF
- Nominal voltage
25 V
- Tolerance ±
20 %
- Height
11.0 mm
- (Ø)
5 mm
- Content
1 pc(s)
- Material
Aluminium
- Width
5 mm
- Length
11.0 mm
- RoHS-compliant
Yes
- Type
JTL476M025T2ABC11L
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
55 °C
Documents & Downloads
Datasheet
Datasheet 3463007 Jamicon Electrolytic capacitor Radial lead 2 mm 47 µF 25 V 20 % (Ø x H) 5 mm x 11.0 mm 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3463007 Jamicon Electrolytic capacitor Radial lead 2 mm 47 µF 25 V 20 % (Ø x H) 5 mm x 11.0 mm 1 pc(s) Tape
Description
Jamicon electrolytic capacitors radial
