Kern OSE421 Stereo microscope Binocular 40 x Reflected light, Transmitted light

EAN:
Part number:
Item no:
1/3
Datasheet (PDF)
Unavailable

Sales and shipping:
Conrad ElectronicTerms & Conditions

Highlights & Details

Stereo microscope OSE 421

  • Stereo (enough)
  • Binocular
  • LED lighting

Technical specifications

Product type

Stereo microscope

Type

Binocular

Type

Upright

Optical magnification (min.)

20 x

Optical magnification (max.)

40 x

Clearance (min.)

57 mm

Lighting type

Reflected light

Transmitted light

Bulb type

LED (monochrome)

Bulb rating

1 W

Operating voltage

100 - 240 V / AC

Dim

(L x W x H) 20 x 18 x 30 cm

Length

20 cm

Width

18 cm

Height

30 cm

Weight

2.2 kg

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 2255661 Kern OSE421 Stereo microscope Binocular 40 x Reflected light, Transmitted light

User & Safety Instructions

User & Safety Instructions 2255661 Kern OSE421 Stereo microscope Binocular 40 x Reflected light, Transmitted light

Information

Information 2255661 Kern OSE421 Stereo microscope Binocular 40 x Reflected light, Transmitted light

Description

THE KERN OSE-42 has been specially developed for schools and workshops thanks to its integrated handle and stable mechanical stand
The standard LED-on and transmitted light illumination can be switched in optionally for the optimum illumination of your sample. Even the mobile use of the OSE 422 is no problem with rechargeable batteries
Despite the low price, it has very good optical properties, which enable sharp pictures over a large field of vision
An interchangeable lens with predefined magnifications is available for fast and efficient working
The eyepieces are fixed in the tube to protect them from loss or damage
A special feature of this variable and at the same time robust microscope series is the stable and precisely adjustable mechanism of the microscope stand, which also impresses through its functionality and its ergonomic design
A large selection of eyepieces as well as various additional external lighting units are available as accessories
Field of application: Training, in vitro fertilization, detection of parasites, zoology, botany, tissue preparation, section, quality control
Applications/Samples: Specimens with focus on spatial impression, zoom with variable magnification (depth, thickness) e.g. Insects, seeds, circuit boards, components

This text is machine translated.

Features

  • Contrast methods: Light field (standard)
  • Eyepieces: WF 10x/Ø20mm
  • Field of vision: Ø20-10mm
  • Lenses: 2x/4x
  • Optical system: Greenough
  • working distance: 57mm
  • Stands: Mechanical
  • lighting: 1W LED (transmitted light + reflected light)

Scope of delivery

  • Dust protection hood
  • Eyecups
  • Operating instructions
  • Power cable;
  • Spare fuse
  • Stand insert black/white
  • Frosted glass stand insert

Accessories

(*All information is plus legal VAT)

The necessary accessories are required to use the article as described.
