Kern Platform scales BID 1T-4LM Weight range 1500 kg Readability 500 g via PSU Dark grey
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Display type: LCD
- Display digit height - large: 25 mm
- Weight range
1500 kg
- Product type
Platform scales
- Readability
500 g
- Display
Digital
- Power supply (LOV)
via PSU
Manufacturer's standards (no certificate)
- Factory colour
Dark grey
- Dim
(L x W x H) 1500 x 1500 x 108 mm
- Weight
155 kg
- Weight resolution
500 g
- Calibratable
Yes
- Weighing plate
Steel (powder-coated)
- Width
1500 mm
- Height
108 mm
- Length
1500 mm
- Reproducibility
0.5 kg
- Type
BID 1T-4LM
- Features
Calibratable
Calibratable
- Top plate (width)
1500 mm
- Top plate (length)
1500 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2498132 Kern Platform scales BID 1T-4LM Weight range 1500 kg Readability 500 g via PSU Dark grey
User & Safety Instructions
User & Safety Instructions 2498132 Kern Platform scales BID 1T-4LM Weight range 1500 kg Readability 500 g via PSU Dark grey
Information
Information 2498132 Kern Platform scales BID 1T-4LM Weight range 1500 kg Readability 500 g via PSU Dark grey
Description
Weighing bridge made of non-slip steel checker plate, 4 load cells, alloyed steel, silicone-coated, IP67. Easy leveling of the weighing bridge as well as access to the junction box from above. Evaluation unit: For details see Kern KIB-TM. Summing of weight values and counting parts. Thanks to interfaces such as RS-232 or USB, WLAN, Bluetooth, Ethernet (optional), the scales can be easily integrated into existing networks and facilitates data exchange between scales and PCs or printers. Query and remote control of the scale via external control devices or computers using Kern Communication Protocol (KCP). The KCP is a standardized interface command set for CORE scales and other instruments that allows the retrieval and control of all relevant parameters and device functions. Kern devices with KCP can be connected to computers, industrial controls and other digital systems very easily. The KCP protocol is largely compatible with the MT-SICS protocol.
This text is machine translated.
This text is machine translated.
Features
- Weighing bridge. Dust and splash-water protection IP67. Welded platform. Comfortable leveling of the weighing bridge. Sum. Interfaces. Query and remote control of the scale.
Scope of delivery
- Power supply with travel adapter: OFF, CH, EURO, UK, US.
Hints
The selected product is a calibration approved part.If there is a need to be calibrated according to EU directives, please order the conformity assessment (calibration) via the optional accessories.Subsequent initial calibration is not possible.In the case of articles with first-time verification, the right of withdrawal is fundamentally excluded.Under the EU Directive 2014/31/EU, scales must be officially conformity-assessed ("calibrated") when used as follows:a) in the course of business, if the price of a commodity is determined by weighing.b) in the manufacture of medicinal products in pharmacies and in analyzes in the medical and pharmaceutical laboratories.c) for official purposes.d) in the manufacture of prepackages.e) in medicine.
