Klauke 16546 Ring terminal Cross section (max.)=25 mm² Hole Ø=6.5 mm Not insulated Metal 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
2
-
€ 1.25
6
8% = € 0.10
€ 1.15
10
11% = € 0.14
€ 1.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 2
Total (€ 1.25 / piece)
€ 1.84
-32 %
€
Highlights & Details
Klauke 16546 Ring terminal Cross section (max.)=25 mm² Hole Ø=6.5 mm Not insulated Metal 1 pc(s)
- 0.50 - 25 mm²
Technical specifications
- Manufacturer part #
16546
- Type
16546
- max. cross section
25 mm²
- Min. cross section
0.50 mm²
- Content
1 pc(s)
- Factory colour
Metal
- Cross-section range
0.50 - 25 mm²
- Insulation type
Not insulated
- Thread size
M6
- Material (details)
Cu-ETP, tin-plated
- Hole Ø
6.5 mm
- Cross section
25 mm²
- Contact material
Cathode copper, tin plated
- RoHS-compliant
Yes
- Support sleeve
No
- Product type
Ring terminal
Documents & Downloads
Datasheet
Datasheet 736015 Klauke 16546 Ring terminal Cross section (max.)=25 mm² Hole Ø=6.5 mm Not insulated Metal 1 pc(s)
User & Safety Instructions
User & Safety Instructions 736015 Klauke 16546 Ring terminal Cross section (max.)=25 mm² Hole Ø=6.5 mm Not insulated Metal 1 pc(s)
Description
DIN 46234. For conductors such as VDE 0295 standard, class 2, 5 and 6. Hard soldered in crimping area. Grooved profile for improved contact characteristics.
