1/5
Knipex 13 86 200 13 86 200 Multifunction pliers 50 mm² (max) 0 (max) 15 mm (max)
EAN:
Part number:
Item no:
Number
Total (€ 43.69 / piece)
€
Highlights & Details
Electrical installation pliers
- 6 functions in one set of pliers
- Slim design for easy accessibility.
- Clear-cut outside edge on jaw for working on flush-mounted junction boxes
Technical specifications
- Stripping holes for wires: 0.75 / 1.5 / 2.5 mm²; crimp die for cable end sleeves: 0.5 / 2.5 mm²; cable shears with precision blades for Cu and Al cable up to 5 x 2.5 mm²/15 mm diameter; slim design for easy accessibility; screwed joint; isoliertmit multi-component covers; DIN EN 60 900 and VDE standard
- Suitable for
Ferrules
- Operating range (diameter)
15 mm (max)
- Operating range (diameter) (max.)
15 mm
- Working area (cross section)
50 mm² (max)
- Operating range (cross section) (max.)
50 mm²
- Operating range (AWG diameter)
0 awg (max)
- Operating range (AWG cross section) (max.)
0 awg
- Material properties
chrome plated
- Length
200 mm
- Width
85 mm
- Weight
280 g
- Height
20 mm
- Type
13 86 200
- Product type
Multifunction pliers
Variants(All information is without VAT, plus shipping costs)
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 816405 Knipex 13 86 200 13 86 200 Multifunction pliers 50 mm² (max) 0 (max) 15 mm (max)
Description
Multifunctional pliers for electrical installation. For gripping of flat and round materials, bending, deburring, cable cutting, stripping and crimping of wire end sleeves 6 functions in one set of pliers Screwed joint: Precise, frictionless movement Slim design for easy accessibility. Smooth gripping surfaces at tips for gripping individual wires without causing damage; Profiled gripping surfaces and stripping hole for gripping flat or round materials Clear-cut outside edge on jaw for working on flush-mounted junction boxes and deburring feed-through holes Stripping holes for wires: 0.75 – 1.5 mm² and 2.5 mm² Crimp die for cable end sleeves 0.5 – 2.5 mm² Cable shears with precision blades (induction-hardened) for copper and aluminium cable up to 5 x 2.5 mm²/dia. 15 mm Special tool steel in special quality, forged, oil-hardened multi-level
This text is machine translated.
This text is machine translated.
Features
- Multifunctional pliers for electrical installation; For gripping of flat and round materials, bending, deburring, cable cutting, stripping and crimping of wire end sleeves
- 6 functions in one set of pliers
- Smooth gripping surfaces at tips for gripping individual wires without causing damage; Profiled gripping surfaces and stripping hole for gripping flat or round materials
- Clear-cut outside edge on jaw for working on flush-mounted junction boxes and deburring feed-through holes
- Stripping holes for wires: 0.7 – 1.5 and 2.5 mm²
- Crimp die for cable end sleeves 0.5 – 2.5 mm²
- Cable shears with precision blades (induction-hardened) for copper and aluminium cable up to 5 x 2.5 mm²/dia. 15 mm
- Grip without opening pliers fully (intelligent latching mechanism in the spring assisted version). The blades remains closed and protected
- Slim design for easy accessibility.
- Screwed joint: Precise, frictionless movement
- High-grade special tool steel, forged, oil-hardened.
